3 Hardware
Control unit
cobas® 4800
System
Systenz Manual
• Code 128, subset B and C
€iEjl
For supported characters for the code 128 barcode type, see Barcode reader
(p.
63)
• Data matrix (Roche-manufactured reagents only)
• GTIN (inciuding JAN) This barcode type is not enabled by default. 1f you require
this barcode type, contact Roche Service.
• Interleaved 2 of 5. This barcode type is not enabled by default. 1f you require this
barcode type, contact Roche Service.
Usage The
barcode label is read
by
holding the head of the barcode reader in close proximity
to the
barcode label and then pressing the button on the barcode reader. The barcode
ID is
then automatically read and displayed on the screen.
Be sure to hold the head of the hand-held barcode reader over the correct barcode label.
It is recommended to visually verify the displayed scanned characters with the human
readable characters on the barcode label.
Figure 3-36
Hand-held barcode reader
Technical specification of the control unit
Software
Operating system
Windows
7
Database
Oracle Database Enterprise Edition
Hand-held barcode reader
Type
1T4600
Interface
The hand-held barcode reader is connected to the control unit
through the USB interface.
Skew angle
±40 degrees
Pitch
angle
±40 degrees
Motion
tolerance
10 cm (4 in) per second
Scan
contrast
45% minimum for Matrix codes
3 7.5% minimum for all others
Temperature
Operating:
0-50°C
(32-122°F)
Storage: -40
to +70°C
(-40 to +158°F)
Humidity
0-95%
non-condensing
Roche
Diagnostics
70
System Manual Version 1.0
