cobas e 411 analyzer
Roche Diagnostics
34
of 61 Host Interface Manual for use in the US
•
Document Version 2.3
1907-05-0816
Message termination record
Elecsys format (upload, download), cobas format (upload, download)
L|1|N [CR]
(1)(2)(3)
Pos No Field Type Max EV CV
Comments
Elecsys Type Format cobas Type Format
1 (1) Record Type ID ST 1 X R L is fixed.
2 (2) Sequence Number NM 6 X R Indicates sequence No. Normally it is 1.
3 (3) Termination Code ST 1 X R Indicates the end of
communication record.
(Can be omitted)
See table below.
N: Normal end
E: Receiving error, hardware
error, application error
Table 12: Message termination record
Message Message Communication Status Termination Code
Inquiry Normal With response data F
Without response data I
Abnormal All data in record is not defined
(inapplicable message error)
Q
Receiving error
Hardware error
Application error
E
Response, upload download Normal - (*1)
Abnormal All data in record is not defined
(inapplicable message error)
Receiving error
Hardware error
Application error
E
Invalid Record Abnormal Receiving error
Hardware error
Application error
E
(*1) The device does not transmit Termination Code when response or receiving message at download is normal.
Table 14: Termination code list (Elecsys type format)
