Rockwell Automation 1768-L45 User Manual

118 Publication IASIMP-QS003B-EN-P - October 2009
Chapter 10 Add Distributed Point I/O Modules to the Project
6. In the New Module
dialog box:
a. Enter a Name for the
adapter.
b. Enter the IP Address
recorded in Appendix
A.
c. Select the Chassis Size,
which is the exact
number of POINT
I/O modules plus one
for the adapter.
This example uses 2.
d. Select Disable Keying.
e. Uncheck Open Module
Properties.
f. Click OK.
7. Right-click 1734-AENT
adapter and select New
Module.
