Preface
Additional Resources
These resources contain information about related products from
Rockwell Automation.
Resource Description
CompactLogix Controllers Specifications Technical Data,
publication 1769-TD005
Provides CompactLogix controller specifications for all CompactLogix controllers.
Armor CompactLogix Controllers Installation Instructions,
publication 1769-IN021
Describes how to install the Armor™ CompactLogix controllers.
1769-SDN DeviceNet Scanner Module User Manual, publication 1769-UM009
Describes how to use the 1769-SDN to back up your CompactLogix 5370 L2 or L3 controller.
Compact High-speed Counter Module User Manual, publication 1769-UM006 Describes high-speed counter operation for standalone 1769-HSC when used with L2 and L3
Compact controllers and embedded high-speed counters in L2 embedded controllers.
Compact I/O DeviceNet Scanner Module Installation Instructions,
publication 1769-IN060
Describes how to install the Compact I/O™ modules.
Compact I/O Expansion Power Supplies Installation Instructions, publication
1769-IN028
Describes how to wire the 1769 Compact I/O power supply.
Compact I/O Modules Installation Instructions, publication 1769-IN088 Describes how to install any 1769 Compact I/O module.
CompactLogix 5370 L1 Controllers Quick Start, publication IASIMP-QS024 Describes basic tasks to design, install, and start a CompactLogix 5370 L1 control system.
CompactLogix 5370 L2 Controllers Quick Start, publication IASIMP-QS025
Describes basic tasks to design, install, and start a CompactLogix 5370 L2 control system.
CompactLogix 5370 L3 Controllers Quick Start, publication IASIMP-QS023 Describes basic tasks to design, install, and start a CompactLogix 5370 L3 control system.
CompactLogix System Selection Guide, publication 1769-SG001 Describes available components for selecting a CompactLogix system.
Electronic Keying in Logix5000 Control Systems Application Technique,
publication LOGIX-AT001
Describes the types of Electronic Keying available in Logix5000 control systems.
Ethernet Design Considerations Reference Manual, publication ENET-RM002 Describes the following concepts that you must consider when designing a control system that
includes an EtherNet/IP network:
• EtherNet/IP overview
• Ethernet infrastructure
• EtherNet/IP protocol
EtherNet/IP Embedded Switch Technology Application Guide,
publication ENET-AP005
Describes how to use a DLR network topology.
Execution Time and Memory Use for Logix5000 Controller Instructions
Reference Manual, publication 1756-RM087
Assists in estimating the memory use and execution time of programmed logic and in selecting
among different programming options.
Integrated Motion on the EtherNet/IP Network: Configuration and Startup User
Manual, publication MOTION-UM003
Describes how to configure an Integrated Motion over
EtherNet/IP motion application and to start up that motion solution in a Logix5000™ control
system.
Logix5000 Controllers Add On Instructions Programming Manual,
publication 1756-PM010
Shows how to use Add-On Instructions for the Logix Designer application.
Logix5000 Controllers Common Procedures Programming Manual,
publication 1756-PM001
Provides links to a collection of programming manuals that describe how you can use
procedures that are common to all Logix5000 controller projects.
