172 Rockwell Automation Publication 1769-UM021I-EN-P - May 2018
Chapter 7 Use I/O Modules with CompactLogix 5370 L1 Controllers
Configure I/O
Complete these steps to add a 1734 POINT I/O module to your
CompactLogix 5370 L1 control system.
1. Right-click PointIO and choose New Module.
You can also right-click Expansion I/O.
2. Select the desired I/O module and click Create.
The New Module dialog box appears.
