Rockwell Automation Allen-Bradley PowerFlex 700S Programming Manual

134 Rockwell Automation Publication 20D-PM001D-EN-P - March 2019
Chapter 2 Programming and Parameters
Preset Speed 2 15
Preset Speed 3 16
Preset Speed 4 17
Preset Speed 5 18
Preset Speed 6 19
Preset Speed 7 20
Pt-Pt Accel Time 759
Pt-Pt Decel Time 760
Pt-Pt Filt BW 761
Pt-Pt Posit Ref 758
PWM Frequency 402
Pwr Strct Mode 420
Ramped Spd Ref 43
Rated Amps 400
Rated Slip Freq 486
Rated Volts 401
Real2DInt In 1050
Real2DInt Result 1052
Real2DInt Scale 1051
Regen Power Lim 128
RegisLtch0 Value 235
RegisLtch0/1Cnfg 236
RegisLtch0/1Ctrl 237
RegisLtch0/1Stat 238
RegisLtch1 Value 239
Reslvr0 CableBal 276
Reslvr0 Carrier 273
Reslvr0 In Volts 274
Reslvr0 SpdRatio 272
Reslvr0 TP Data 271
Reslvr0 TP Sel 270
Reslvr0 Type Sel 277
Resolver0 Cnfg 268
Resolver0 Status 269
Rev Speed Limit 75
Rly Out3 Bit 857
Rly Out3 Data 856
Rly Out3 OffTime 859
Rly Out3 On Time 858
Rly Out3 Sel 855
Rotor Resistance 502
Rslvr0 XfrmRatio 275
RsTempCoefAdjust 590
RsTmpCoefAdjstEn 591
Run Boost 528
Rx Buf Data Type 933
Rx Dir Data Type 928
S Curve Time 34
Saved Events 436
Scaled Spd Fdbk 72
Scaled Spd Ref 46
Sel Switch Ctrl 1022
Sel Swtch In00 1029
Sel Swtch In01 1030
Param Name Text Parameter #
Sel Swtch In02 1031
Sel Swtch In03 1032
Sel Swtch In04 1033
Sel Swtch In05 1034
Sel Swtch In06 1035
Sel Swtch In07 1036
Sel Swtch In08 1037
Sel Swtch In09 1038
Sel Swtch In10 1039
Sel Swtch In11 1040
Sel Swtch In12 1041
Sel Swtch In13 1042
Sel Swtch In14 1043
Sel Swtch In15 1044
Selected Spd Ref 40
Selected SpdRefA 49
Selected SpdRefB 50
Selected Trq Ref 319
SelSwtch DIntOut 1046
SelSwtch RealOut 1045
SrLssAngleStblty 537
SrLss VoltStblty 538
SrLss StbltyFilt 539
Servo Lock Gain 85
Set Speed Lim 171
Setpt 1 Data 172
Setpt 1 Limit 174
Setpt 2 Data 175
Setpt 2 Limit 177
Setpt1 TripPoint 173
Setpt2 TripPoint 176
-Sft OvrTrvlCnfg 396
Skip Speed 1 136
Skip Speed 2 137
Skip Speed 3 138
Skip Speed Band 139
SL BOF Err Accum 896
SL BOF Err Limit 899
SL BOF Error 897
SL Buf Data Rx00 934
SL Buf Data Rx01 935
SL Buf Data Rx02 936
SL Buf Data Rx03 937
SL Buf Data Rx04 938
SL Buf Data Rx05 939
SL Buf Data Rx06 940
SL Buf Data Rx07 941
SL Buf Data Rx08 942
SL Buf Data Rx09 943
SL Buf Data Rx10 944
SL Buf Data Rx11 945
SL Buf Data Rx12 946
SL Buf Data Rx13 947
SL Buf Data Rx14 948
Param Name Text Parameter #
SL Buf Data Rx15 949
SL Buf Data Rx16 950
SL Buf Data Rx17 951
SL Buf Data Rx18 952
SL Buf Data Rx19 953
SL Buf Data Rx20 954
SL Buf Data Rx21 955
SL Buf Data Rx22 956
SL Buf Data Rx23 957
SL Buf Data Rx24 958
SL Buf Data Rx25 959
SL Buf Data Rx26 960
SL Buf Data Rx27 961
SL Buf Data Rx28 962
SL Buf Data Rx29 963
SL Buf Data Tx00 970
SL Buf Data Tx01 971
SL Buf Data Tx02 972
SL Buf Data Tx03 973
SL Buf Data Tx04 974
SL Buf Data Tx05 975
SL Buf Data Tx06 976
SL Buf Data Tx07 977
SL Buf Data Tx08 978
SL Buf Data Tx09 979
SL Buf Data Tx10 980
SL Buf Data Tx11 981
SL Buf Data Tx12 982
SL Buf Data Tx13 983
SL Buf Data Tx14 984
SL Buf Data Tx15 985
SL Buf Data Tx16 986
SL Buf Data Tx17 987
SL Buf Data Tx18 988
SL Buf Data Tx19 989
SL Buf Data Tx20 990
SL Buf Data Tx21 991
SL Buf Data Tx22 992
SL Buf Data Tx23 993
SL Buf Data Tx24 994
SL Buf Data Tx25 995
SL Buf Data Tx26 996
SL Buf Data Tx27 997
SL Buf Data Tx28 998
SL Buf Data Tx29 999
SL Clr Events 916
SL Comm TP Data 893
SL Comm TP Sel 892
SL CommLoss Cnfg 384
SL CommLoss Data 383
SL CRC Err Accum 894
SL CRC Err Limit 898
SL CRC Error 895
SL Dir Data Rx00 929
