Rockwell Automation Publication 20D-PM001D-EN-P - March 2019 17
Chapter 2
Programming and Parameters
This chapter provides a complete listing of the PowerFlex® 700S Phase II drive
parameters. The parameters can be programmed (viewed/edited) using a Human
Interface Module (HIM). Refer to Human Interface Module Overview
on page
151
for information on using the HIM to view and edit parameters. As an
alternative, programming can also be performed using DriveTools™ software and a
personal computer.
Firmware Compatibility
PowerFlex 700S firmware revision 6.xxx and earlier can only be used with control
boards that were designed to operate with 6.xxx or earlier firmware, series A con-
trol boards. PowerFlex 700S firmware revision firmware 7.xxx and greater can
only be used with control boards that were designed to operate with 7.xxx or
greater, series B control boards.
If you attempt to download a firmware revision that is not compatible with the
control board on the drive, a series of error messages appear. If these error
messages appear, confirm the revision of the control board, and select a firmware
revision download that is compatible with the control board version.
Topic Page
Firmware Compatibility 17
If you attempt to download a firmware revision that is not compatible with the control
board on the drive, a series of error messages appear. If these error messages appear,
confirm the revision of the control board, and select a firmware revision download that is
compatible with the control board version.
17
How Parameters are Organized 20
Parameter Data in Linear List Format 32
Parameter Cross Reference By Name 130
Table 2 - Compatible Revisions
Control Board Version Compatible Firmware Revisions
Series A 6.xxx and previous
Series B 7.xxx and later
