Rockwell Automation Publication 20D-PM001D-EN-P - March 2019 167
Application Notes Appendix B
Setpt 1 Data
Provides data for comparison of Par 172 [Setpt 1 Data] to Par 173 [Setpt1
TripPoint], driving bit 16 “At Setpt 1” of Par 155 [Logic Status].
Figure 5 - At Setpoint 1 Status
Setpt 2 Data
Provides data for comparison of Par175 [Setpt 2 Data] to Par 176 [Setpt2
TripPoint], driving bit 17 “Above Setpt 2” of Par 155 [Logic Status].
Figure 6 - Above Setpoint 2 Status
400 SVO Motor 1.5 MC-M20 4 1500 280 5.4 - -
2.2 MC-M20 4 1500 280 7.3 - -
3.7 MC-M20 4 1500 280 12.3 - -
5.5 MC-M20 4 1500 280 17.3 - -
7.5 MC-M20 4 1500 280 22 - -
11 MC-M20 4 1500 280 34 - -
15 MC-M20 4 1500 280 42 - -
22 MC-M20 4 1500 280 58.5 - -
22 MC-M20 4 1500 280 58.5 - -
30 MC-M20 6 1000 280 88 - -
37 MC-M20 6 1000 280 125 - -
(1) Manufacturer, Reliance Electric-Japan, catalog number for ordering.
Motor Type
Motor
(kW)
Type
(Catalog No.)
(1)
Poles Base Speed (RPM)
Voltage
(Vrms)
Rated Current
(Arms) Ex. Current (Arms) GD2 (Kg/m
2
)
P173 [Setpt1 TripPoint]
P172 [Setpt 1 Data]
bit 16 "At Setpt 1" turns on
bit 16 "At Setpt 1" turns off
P173 [Setpt1 TripPoint] + P174 [Setpt 1 Limit]
P173 [Setpt1 TripPoint] + 2 x P174 [Setpt 1 Limit]
P173 [Setpt1 TripPoint] - P174 [Setpt 1 Limit]
P173 [Setpt1 TripPoint] - 2 x P174 [Setpt 1 Limit]
Time
bit 16 "At Setpt 1" turns off
bit 16 "At Setpt 1" turns off
bit 16 "At Setpt 1" turns off
bit 16 "At Setpt 1" turns off
bit 16 "At Setpt 1" turns on
bit 16 "At Setpt 1" turns on
bit 16 "At Setpt 1" turns on
bit 16 "At Setpt 1" turns on
P176 [Setpt 2 TripPoint] - P177 [Setpt 2 Limit]
P175 [Setpt 2 Data]
bit 17 "Above Setpt 2" turns on
bit 17 "Above Setpt 2" turns off
0
Time
P176 [Setpt 2 TripPoint]
P176 [Setpt 2 TripPoint] - 2 x P177 [Setpt 2 Limit]
