200 Rockwell Automation Publication 20D-PM001D-EN-P - March 2019
Appendix D PowerFlex 700S Permanent Magnet Motor Specifications
MPM-B2152C 480 12.3 133.3 2000 5.60 8 39.2 36.70 2500
MPM-B2152F 480 18.7 166.7 2500 5.90 8 69.3 33.00 4500
MPM-B2152M 480 21.0 166.7 2500 5.90 8 54.0 30.00 5000
MPM-B2153B 480 12.7 116.7 1750 6.80 8 42.4 48.00 2000
MPM-B2153E 480 19.3 133.3 2000 7.20 8 69.7 48.00 3000
MPM-B2153F 480 22.1 133.3 2000 7.20 8 69.6 45.00 3800
MPM-B2154B 480 13.9 116.7 1750 6.90 8 69.3 62.80 2000
MPM-B2154E 480 18.3 133.3 2000 7.50 8 69.5 56.00 3000
MPM-B2154F 480 19.8 133.3 2000 7.50 8 59.3 56.00 3300
MPL-A310P 230 3.4 294.0 4410 0.73 8 9.9, 1.58 5000
MPL-A310F 230 2.1 185.3 2780 0.46 8 6.6 1.58 3000
MPL-A320P 230 6.4 271.3 4070 1.30 8 20.9 3.05 5000
MPL-A320H 230 4.6 208.7 3130 1.00 8 13.6 3.05 3500
MPL-A330P 230 8.5 280.7 4210 1.80 8 26.9 4.08 5000
MPL-A420P 230 9.0 268.7 4030 2.00 8 32.5 4.74 5000
MPL-A430P 230 11.9 234.0 3510 2.20 8 47.4 5.99 5000
MPL-A430H 230 8.6 184.7 2770 1.80 8 31.8 6.21 3500
MPL-A4520P 230 12.4 234.0 3510 2.20 8 35.4 5.99 5000
MPL-A4520K 230 10.6 223.3 3350 2.10 8 30.4 5.99 4000
MPL-A4530F 230 9.5 144.7 2170 1.90 8 29.7 8.36 2800
MPL-A4530K 230 14.4 196.0 2940 2.50 8 43.8 8.13 4000
MPL-A4540C 230 6.6 93.3 1400 1.50 8 20.5 10.20 1500
MPL-A4540F 230 13.0 162.0 2430 2.60 8 38.2 10.20 3000
MPL-A520K 230 16.3 208.0 3120 3.50 8 46.0 10.70 4000
MPL-A540K
(1)
230 29.3 180.7 2710 5.50 8 84.9 19.40 4000
MPL-A560F 230 29.3 125.3 1880 5.50 8 84.9 27.90 3000
MPL-B310P 460 1.7 310.0 4650 0.77 8 3.0 1.58 5000
MPL-B320P 460 3.2 313.3 4700 1.50 8 5.0 3.05 5000
MPL-B330P 460 4.3 274.0 4110 1.80 8 7.0 4.18 5000
MPL-B420P
(1)
460 4.5 255.3 3830 1.90 8 9.2 4.74 5000
MPL-B430P
(1)
460 6.5 214.0 3210 2.20 8 12.0 6.55 5000
MPL-B4520P 460 6.0 236.7 3550 2.10 8 17.0 5.65 5000
MPL-B4530F 460 5.0 162.0 2430 2.10 8 13.4 8.25 3000
MPL-B4530K 460 7.8 200.7 3010 2.60 8 19.1 8.25 4000
MPL-B4540F 460 6.4 162.0 2430 2.60 8 16.3 10.20 3000
MPL-B4560F 460 8.3 144.7 2170 3.20 8 25.5 14.10 3000
MPL-B520K
(1)
460 8.1 208.0 3120 3.50 8 23.3 10.70 4000
MPL-B540K
(1)
460 14.5 177.3 2660 5.40 8 42.4 19.40 4000
MPL-B560F 460 14.5 130.7 1960 5.50 8 42.4 26.80 3000
MPL-B580F 460 18.4 132.7 1990 7.10 8 66.5 34.00 3000
MPL-B580J
(1)
460 22.6 148.0 2220 7.90 8 66.5 34.00 3800
MPL-B640F 460 22.7 106.0 1590 6.11 8 46.0 36.70 3000
MPL-B660F 460 27.2 81.3 1220 6.15 8 67.9 48.00 3000
MPL-B680D 460 24.0 94.0 1410 9.30 8 66.5 62.80 2000
MPL-B680F 460 33.9 79.3 1190 7.50 8 67.9 60.00 3000
MPL-B860D
(1)
460 33.6 96.0 1440 12.50 8 67.5 83.10 2000
MPL-B880C
(1)
460 33.6 72.7 1090 12.60 8 69.0 110.00 1500
MPL-B880D
(1)
460 40.3 86.7 1300 15.00 8 113.2 110.00 2000
MPL-B960B
(1)
460 29.7 62.0 930 12.70 8 63.6 130.00 1200
Parameter No. 1 2 3 4 5 7
Model Number Motor NP Volts
(line to line V rms)
Motor NP FLA
(A rms)
Motor NP
Frequency
(Hz)
Motor NP RPM
(oper. rpm)
Motor NP
Power (KW)
Motor
Poles
Current peak
(A rms)
System Cont. Stall
Torque (N•m)
Motor Max
RPM
(rpm)
