Rockwell Automation Publication 20D-PM001D-EN-P - March 2019 153
Human Interface Module Overview Appendix A
Alternate (ALT) Functions
Follow these steps to use an ALT function.
1. Press the ALT key and release it.
2. Press the programming key for the desired function as identified in
Tab l e 8
.
Table 8 - ALT Key Functions
Access the Start-Up Routine
The start-up routine asks simple yes or no questions and prompts you to input
required information. To access the Start-Up routine from the User Display
screen:
1. On the User Display screen, press .
The Main menu displays.
2. Use the key to scroll to “Start-Up” in the list and press .
3. select “Continue” and press .
The PowerFlex 700S Start-Up screen displays.
4. Follow the prompts as necessary.
ALT Key and then … Function
S.M.A.R.T. Function not available.
View Allows the selection of how parameters will be viewed or detailed
information about a parameter or component.
Lang Function not available.
Auto/Man Function not available.
Remove Allows HIM removal without causing a fault if the HIM is not the last
controlling device and does not have manual control of the drive.
Exp Allows the value to be entered as an exponent.
Param # Allows entry of a parameter number for viewing/editing.
