Chapter 2 Programming and Parameters
To DriveLogix15 641
To DriveLogix16 642
To DriveLogix17 643
To DriveLogix18 644
To DriveLogix19 645
To DriveLogix20 646
Torque En Dly 501
Torque Neg Limit 126
Torque Pos Limit 125
Torque Ref1 111
Torque Ref1 Div 112
Torque Ref2 113
Torque Ref2 Mult 114
Torque Step 116
Torque Trim 115
Total Inertia 9
Trend Control 556
Trend In1 DInt 570
Trend In1 Real 571
Trend In2 DInt 574
Trend In2 Real 575
Trend In3 DInt 578
Trend In3 Real 579
Trend In4 DInt 582
Trend In4 Real 583
Trend Mark DInt 567
Trend Mark Real 568
Trend Out1 DInt 572
Trend Out1 Real 573
Trend Out2 DInt 576
Trend Out2 Real 577
Trend Out3 DInt 580
Trend Out3 Real 581
Trend Out4 DInt 584
Trend Out4 Real 585
Trend PreSamples 566
Trend Rate 559
Trend State 558
Trend Status 557
Trend Trig Bit 565
Trend Trig Data 564
Trend TrigA DInt 560
Trend TrigA Real 561
Trend TrigB DInt 562
Trend TrigB Real 563
TrendBuffPointer 569
Trq CurFdbk (Iq) 499
Trq NegLim Actl 124
Trq PosLim Actl 123
Trq Ref TP Data 131
Trq Ref TP Sel 130
Tune Test Status 165
Tx Buf Data Type 969
Tx Dir Data Type 964
Param Name Text Parameter #
UserData Dint 01 1002
UserData Dint 02 1003
UserData Dint 03 1004
UserData Dint 04 1005
UserData Dint 05 1006
UserData Dint 06 1007
UserData Dint 07 1008
UserData Dint 08 1009
UserData Dint 09 1010
UserData Dint 10 1011
UserData Real 01 1012
UserData Real 02 1013
UserData Real 03 1014
UserData Real 04 1015
UserData Real 05 1016
UserData Real 06 1017
UserData Real 07 1018
UserData Real 08 1019
UserData Real 09 1020
UserData Real 10 1021
UserFunct Actual 1001
UserFunct Enable 1000
V/Hz Mode Config 513
V/Hz Status 540
Vds Command 498
Vds Fdbk Filt 441
Vds Max 438
Vds Min 440
VirtEncPositFast 1160
Virt Encdr Dlyed 63
Virt Encdr Posit 62
Virt Encoder EPR 61
Virtual Edge/Rev 225
Voltage Class 403
VoltFdbkLossCnfg 394
VPL Build Number 315
VPL Firmware Rev 314
VPL Mem Address 479
VPL Mem Data Bit 482
VPL Mem Data Flt 481
VPL Mem Data Int 480
VPL Mem Link Flt 484
VPL Mem Link Int 483
VPL Mem Password 478
Vqs Command 497
Vqs Fdbk Filt 442
Vqs Max 437
Vqs Min 439
VqsReg Err Lmt 588
VqsReg Off Freq 462
VqsReg On Hystr 592
Vuv Fdbk Offset 549
Vvw Fdbk Offset 550
Wake Level 280
Param Name Text Parameter #
Wake Time 281
Write Mask 669
Write Mask Act 712
X Notch Attenu 778
X Notch FiltFreq 779
X Offst SpdFilt 756
XReg Integ HiLim 773
XReg Integ LoLim 772
XReg Integ Out 774
XReg Spd HiLim 776
XReg Spd LoLim 775
Xsync Gen Period 787
Xsync In 1 788
Xsync In 2 790
Xsync In 3 793
Xsync Out 1 789
Xsync Out 2 791
Xsync Out 2 Dly 792
Xsync Out 3 794
Xsync Out 3 Dly 795
Xsync Status 786
Zero Speed Lim 160
