Chapter 3 Troubleshooting
Table 4 - DriveLogix5730 Controller Status Indicator Descriptions
LED Color/Condition: Description:
RUN off The controller is in Program or Test mode.
solid green The controller is in Run mode.
I/O off Either:
There are no devices in the I/O configuration of the controller.
The controller does not contain a project (controller memory is empty).
solid green The controller is communicating with all the devices in its I/O configuration.
flashing green One or more devices in the I/O configuration of the controller are not responding.
flashing red The controller is not communicating to any devices.
The controller is faulted.
FORCE off No tags contain I/O force values.
I/O forces are inactive (disabled).
solid amber I/O forces are active (enabled).
I/O force values may or may not exist.
flashing amber One or more input or output address have been forced to an On or Off state, but
the forces have not been enabled.
COM off No RS-232 activity.
flashing green RS-232 activity.
BAT off The battery supports memory.
solid red Either the battery is:
• Not installed.
• 95% discharged and should be replaced.
OK off No power is applied.
flashing red If the controller is: Then:
a new controller the controller requires a firmware update
not a new controller A major fault occurred. To clear the fault, either:
Turn the key switch from PROG to RUN to PROG
Go online with RSLogix 5000 software
solid red The controller detected a non-recoverable fault, so it cleared the project from
memory. To recover:
• Cycle power to the chassis.
• Download the project.
• Change to Run mode.
• If the OK LED remains solid red, contact your Rockwell Automation
representative or local distributor.
solid green Controller is OK.
flashing green The controller is storing or loading a project to or from nonvolatile memory.
