Rockwell Automation Allen-Bradley PowerFlex 755T Installation Instructions

Rockwell Automation Publication 750-IN118A-EN-P - May 2021 103
Chapter 4 Power Wiring
Table 16 - Frame 8 Configured Input Bay AC Line Input Protection Fuses
Drive Fuses
Input
Rating
Applied
Rating
Cont.
Output
Amps
Duty
Input
Amps
Manufacturer
Manufacturer
Part Number
Specification
400V
160 kW
367 Light 352 Mersen AJT500 CLASS J -600V, 500 A
302 Normal 290
Cooper
Bussmann
LPJ-400SP CLASS J -600V, 400 A
260 Heavy 250 LPJ-400SP CLASS J -600V, 400 A
200 kW
460 Light 442 LPJ-600SP CLASS J -600V, 600 A
367 Normal 352 Mersen AJT500 CLASS J -600V, 500 A
302 Heavy 290
Cooper
Bussmann
LPJ-400SP CLASS J -600V, 400 A
250 kW
540 Light 518 170M6463 CLASS aR -690V, 900 A
460 Normal 442 LPJ-600SP CLASS J -600V, 600 A
367 Heavy 352 LPJ-600SP CLASS J -600V, 600 A
315 kW
585 Light 562 170M6463 CLASS aR -690V, 900 A
540 Normal 518 170M6463 CLASS aR -690V, 900 A
460 Heavy 442 LPJ-600SP CLASS J -600V, 600 A
315 kW
650 Light 624 170M6466 CLASS aR -690V, 1250 A
585 Normal 562 170M6466 CLASS aR -690V, 1250 A
472 Heavy 453 LPJ-600SP CLASS J -600V, 600 A
355 kW
750 Light 720 170M6466 CLASS aR -690V, 1250 A
650 Normal 624 170M6466 CLASS aR -690V, 1250 A
540 Heavy 518 170M6466 CLASS aR -690V, 1250 A
400 kW
796 Light 764 170M6466 CLASS aR -690V, 1250 A
750 Normal 720 170M6466 CLASS aR -690V, 1250 A
585 Heavy 562 170M6466 CLASS aR -690V, 1250 A
400 kW
832 Light 799 170M6466 CLASS aR -690V, 1250 A
770 Normal 739 170M6466 CLASS aR -690V, 1250 A
650 Heavy 624 170M6466 CLASS aR -690V, 1250 A
480V
250 Hp
361 Light 332 Mersen AJT500 CLASS J -600V, 500 A
302 Normal 278
Cooper
Bussmann
LPJ-400SP CLASS J -600V, 400 A
248 Heavy 228 LPJ-400SP CLASS J -600V, 400 A
300 Hp
430 Light 396 LPJ-600SP CLASS J -600V, 600 A
361 Normal 332 Mersen AJT500 CLASS J -600V, 500 A
302 Heavy 278
Cooper
Bussmann
LPJ-400SP CLASS J -600V, 400 A
350 Hp
485 Light 446 170M6463 CLASS aR -690V, 900 A
430 Normal 396 LPJ-600SP CLASS J -600V, 600 A
361 Heavy 332 Mersen AJT500 CLASS J -600V, 500 A
400 Hp
545 Light 501
Cooper
Bussmann
170M6463 CLASS aR -690V, 900 A
505 Normal 465 170M6463 CLASS aR -690V, 900 A
430 Heavy 396 LPJ-600SP CLASS J -600V, 600 A
450 Hp
617 Light 568 170M6466 CLASS aR -690V, 1250 A
545 Normal 501 170M6466 CLASS aR -690V, 1250 A
454 Heavy 418 LPJ-600SP CLASS J -600V, 600 A
500 Hp
710 Light 653 170M6466 CLASS aR -690V, 1250 A
617 Normal 568 170M6466 CLASS aR -690V, 1250 A
485 Heavy 446 170M6466 CLASS aR -690V, 1250 A
