Additional Resources
These documents and resources contain additional information that is related
to PowerFlex 755T configured products.
Shipped with the Product
A documentation package is shipped with your product. It contains the
following:
Read and understand this documentation before you install and operate the
drive. Keep the documentation package for future reference.
Online
These documents and resources are not shipped with the product, but are
available online.
Resource Description
Product schematics and drawings Wiring schematics, elevation drawings
PowerFlex 755T Drives Configured to Order Program Product Information,
publication 750-PC108
Provides product information about the configured input bays and configured output bays in
the PowerFlex 755T Drives Configured to Order Program.
PowerFlex 750-Series Products with TotalFORCE Control Product
Information, publication 750-PC100
Provides product information about the PowerFlex 755TL drive, PowerFlex 755TR drive, and
PowerFlex 755TM bus supply.
PowerFlex 755T Drives Configured to Order Program Receiving, Handling, and
Storage Installation Instructions, publication 750-IN110
Provides the basic steps to transport and store the shipping sections of the PowerFlex 755T
Drives Configured to Order Program.
Resource Description
PowerFlex 750-Series Products with TotalFORCE Control Installation
Instructions, publication 750-IN100
Provides the basic steps to install PowerFlex 755TL drives, PowerFlex 755TR drives, and
PowerFlex 755TM bus supplies.
PowerFlex 750-Series Products with TotalFORCE Control Technical Data,
publication 750-TD100
Provides detailed information on:
• Drive and bus supply specifications
• Option specifications
• Fuse and circuit breaker ratings
PowerFlex 750-Series Products with TotalFORCE Control Hardware Service
Manual, publication 750-TG100
Provides detailed information on:
• Preventive maintenance
• Component testing
• Hardware replacement procedures
PowerFlex Drives with TotalFORCE Control Programming Manual (firmware
revision 10.xxx and later), publication 750-PM101
Provides detailed information on:
• I/O, control, and feedback options
• Parameters and programming
• Faults, alarms, and troubleshooting
PowerFlex 750-Series Products with TotalFORCE Control Reference Manual,
publication 750-RM100
Provides detailed setup and programming instructions for common applications.
PowerFlex 750-Series Service Cart Instructions, publication 750-IN105
Provides detailed set-up and operating instructions for the module service cart and DC
precharge module lift.
PowerFlex 755TM Power and Filter Module Storage Hardware Instructions,
publication 750-IN106
Provides detailed installation and usage instructions for this hardware accessory.
Switched Mode Power Supply Specifications Technical Data, publication
1606-TD002
Provides specifications for Bulletin 1606 products and applications. This includes the
optional uninterruptible power supply in the 750-Series configured output option.
Wiring and Grounding Guidelines for Pulse Width Modulated (PWM) AC Drives,
publication DRIVES-IN001
Provides basic information to properly wire and ground PWM AC drives.
EtherNet/IP Network Devices User Manual, ENET-UM006
Describes how to configure and use EtherNet/IP devices to communicate on the EtherNet/IP
network.
Ethernet Reference Manual, ENET-RM002 Describes basic Ethernet concepts, infrastructure components, and infrastructure features.
System Security Design Guidelines Reference Manual, SECURE-RM001
Provides guidance on how to conduct security assessments, implement Rockwell
Automation products in a secure system, harden the control system, manage user access,
and dispose of equipment.
