20 Rockwell Automation Publication 750-IN118A-EN-P - May 2021
Chapter 1 Product Overview
Additional Drive Configuration
Figure 13 - Additional Drive Configuration, Catalog Number Positions 11…13
I
Filtering and CM Cap Configuration
Code
EMC Filtering
(1)
(1) EMC C2 ratings, conducted and radiated (IP54) or EMC C2 conducted only (IP21). C2 solutions kits
are available for frames 8…9.
PE-A
(2)
(2) Configuration does not apply to product type 20G with input types D and E. PE-A jumpers are
removed when bus conditioner for marine applications (-P51) is selected.
PE-B
Reflective Wave
Filtering
Frames
J
(3)
(3) Does not provide a C2 solution (C3 compliant), but does include some filtering.
Yes Installed Removed No 8…9
K
(3)
Yes Installed Removed Yes 8…9
L
(4)
(4) C3 compliant without additional filtering.
No Installed Removed No 8…9
M
(4)
No Installed Removed Yes 8…9
J
Dynamic Braking
(1)
(1) Not available on Frames 8…9.
Code Internal Resistor Internal Transistor Frames
NNo No8…9
K
Door-mounted Human Interface Module (HIM)
Code Operator Interface and Control Frames
A No HIM with TotalFORCE Control 8…9
D
Enhanced LCD, Full Numeric, IP66, NEMA Type 4X/12 with TotalFORCE
Control
8…9
