Rockwell Automation Publication 750-IN118A-EN-P - May 2021 31
Chapter 1 Product Overview
Approximate Weights There are two ways to find weight information about your product:
• For the weight of each shipping section, see the shipping slip for that section.
The weight on the shipping slip is the shipping weight of the section, including
the weight of the bays, skid, any detached parts on the skid, and any lifting
angles.
• For the approximate maximum weight of each configured bay, see the
following table. The approximate weight of the drive bays is listed in the
PowerFlex 750-Series Products with TotalFORCE Control Installation
Instructions, publication 750-IN100
. You can find the weight of your entire
product by adding the weights of all the bays.
Frame
Size
Configured Bay Size
Approximate
Maximum Weight,
kg (lb)
8
Configured input bay, control-only 93 (205)
Configured input bay with fuses, top entry 114 (252)
Configured input bay with fuses, bottom entry 116 (255)
Configured input bay with circuit breaker, top entry 113 (249)
Configured input bay with circuit breaker, bottom entry 114 (252)
Configured output bay with contactor only, top or bottom exit 78 (172)
Configured output bay, with sine-wave filter and contactor, top
or bottom exit
485 (1069)
9
Configured input bay, control-only 93 (205)
Configured input bay with fuses, top entry 290 (639)
Configured input bay with fuses, bottom entry 290 (639)
Configured input bay with circuit breaker, top entry 175 (386)
Configured input bay with circuit breaker, bottom entry 221 (487)
Configured output bays, top exit (two bays together) 1065 (2348)
Configured output bays, bottom exit (three bays together) 1121 (2471)
