46 Rockwell Automation Publication 750-IN118A-EN-P - May 2021
Chapter 3 Mechanical and Electrical Installation
Remove Detached
Installation Hardware
Some configured bays come with hardware that is shipped detached from the
bays. For a list of hardware that is shipped detached from the bays, see the
following sections. The packing slip for each shipping section also lists the
items that are included in the shipping section. Move the detached hardware
off the shipping skid and save for later steps in the installation. We
recommend that you designate a secure temporary storage area for
components that must be installed later in the installation process.
Detached Electrical Connection Hardware
Most electrical connection hardware is contained inside the bays when they
are shipped, but some configured bays come with a separate package
containing some of the electrical connection hardware.
Detached Roof Vent
Some configured bays come with a roof vent. Some roof vents ship detached
from the bay and must be attached later in the installation.
Table 4 - Configured Bays that Come with Detached Electrical Connection Hardware
Frame Configured Bay Connection Hardware Location of Hardware
9
Configured input bay,
fuses, top entry
Flexibar flexible busbar
On the skid with the configured
input bay
Table 5 - Configured Bay Roof Vent Shipping Locations
Frame Configured Bay
Location of Roof Vent and
Hardware when Shipped
8
Configured input bay with fuses, top entry
Already attached to the bay
Configured input bay with fuses, bottom entry
Configured input bay with circuit breaker, top entry
Configured input bay with circuit breaker, bottom entry
9
Configured input bay with input fuses, top entry
Detached, on the skid with
the configured input bay
that the roof vent is used
with
Configured input bay with input fuses, bottom entry
Configured input bay with circuit breaker, top entry
Configured input bay with circuit breaker, bottom entry
