Chapter 1 Product Overview
Figure 12 - PowerFlex 755T Common Bus Inverter Normal Duty Ratings, Catalog Number Positions 8…10
1
45678 111213
_ _ _ __ _ _
23
_ _ _
9
10
_
_
_
H1…H4
H1 H2
PowerFlex 755T Normal Duty Common Bus Inverter Ratings PowerFlex 755T Normal Duty Common Bus Inverter Ratings
400V, 50 Hz Input 480V, 60 Hz Input
Code Amps kW Frame Code Amps Hp Frame
302 302 160
8
302 302 250
8
367 367 200 361 361 300
460 460 250 430 430 350
540 540 315 505 505 400
585 585 315 545 545 450
650 650 355 617 617 500
750 750 400 710 710 600
770 770 400 740 740 650
920 920 500
9
800 800 700
9
1K0 1040 560 960 960 800
1K1 1112 630 1K0 1045 900
1K2 1175 710 1K1 1135 1000
1K4 1463 800 1K3 1365 1100
H3 H4
PowerFlex 755T Normal Duty Common Bus Inverter Ratings PowerFlex 755T Normal Duty Common Bus Inverter Ratings
600V, 60 Hz Input 690V, 50 Hz Input
Code Amps Hp Frame Code Amps kW Frame
242 242 250
8
215 215 200
8
295 295 300 265 265 250
355 355 350 330 330 315
395 395 400 370 370 355
435 435 450 415 415 400
545 545 550 505 505 500
595 580 600
9
565 565 560
9
690 690 700 650 650 630
760 760 800 735 735 710
825 825 900 820 820 800
980 980 1000 920 920 900
