Rockwell Automation Allen-Bradley PowerFlex 755T

Rockwell Automation Publication 750-IN118A-EN-P - May 2021 23
Chapter 1 Product Overview
Figure 16 - Configured Input Bay Options, Catalog Number Positions 21…31
21
-_
S
T
-_ _
22 23
24
-_
U
25
-_
V
26
-_
W
27
-_
X
28
-_
Y
29
-_
Z
30
-_
AA
31
-_
AB
S
Line Cable Entry Location
Code Option Frames
N
No Configured Input Bay
(1)
(1) Sets all configured input bay options to 'N' to allow for options for a configured-output-
bay-only setup.
8…9
(2)
(2) For use on common bus inverters (CBIs), and TL/TR drives only. Not for use with bus
supply.
A Top Cable Entry 8…9
B Bottom Cable Entry 8…9
T
Input Protection
Code Option Frames
NN No Configured Input Bay
8…9
(1)
(1) For use on common bus inverters (CBIs), and TL/TR drives only. Not for use with bus
supply.
P0
Control-only Configured Input Bay (no input
protection)
8…9
P2 Input Fuses 8…9
P3 Circuit Breaker 8…9
U
Input Protection Auxiliary Contacts (Added to IP Device)
Code Option Frames IP Options
NNo Aux Contacts8…9—
A 1xNC Aux Contact 8…9 P2
E CB Aux/Alm Contacts (24V) 8…9 P3
F CB Aux/Alm Contacts (250V) 8…9 P3
V
Input Power Filtering
Code Option Frames
N No Input Filter 8…9
A 3% Input Line Reactor 8…9
B 5% Input Line Reactor 8…9
W
120V Control Power
Code Option Frames
N Customer Provided 120V AC 8…9
A Rockwell Automation® Provided 120V AC 8…9
B RA provided 120VAC (+Additional Va) 8…9
X
24V DC Auxiliary Power
Code Option Frames
N Customer Provided 24V DC Aux Power 8…9
A 24V DC Aux Power Supply 8…9
B 24V DC Aux Power Supply and UPS 8…9
Y
Door-Mounted Operator Station Control Set
Code Option Frames
N No Operator Devices 8…9
A Bus Supply ON/OFF Selector Switch 8…9 (24J)
B Drive Disable Push Button 8…9
C
Pilot Lights
(1)
Only
(1) Pilot lights indicate the following drive statuses: Control Power On (white light), Running
(green light), and Fault (red light).
8…9
D Hand Off Auto (HOA) Switch and Pilot Lights 8…9
E
Local Control
(2)
and Pilot Lights
(2) Local control consists of: Start push button (green), Stop push button (red), and speed
potentiometer
8…9
F HOA Switch, Local Control, and Pilot Lights 8…9
G
HOA Switch, Local Control, Drive Disable Push
Button, and Pilot Lights
8…9
Z
Control Interface
Code Option Frames
N No Control Interface 8…9
A Running and Fault 8…9
B Control Power ON, Running, and Fault 8…9
AA
Voltage Sensing - Door-Mounted Voltage Vision
Code Option Frames
N No Voltage Vision 8…9
A AC Input Indication 8…9
B DC Bus Indication 8…9
C AC Input and DC Bus Indication 8…9
AB
Infrared Viewing Window - Door Mounted for Line
Code Option Frames
N No Infrared Viewing Window 8…9
A Infrared Viewing Window 8…9
