Publication 2100-IN012C-EN-P - April 2009 51
Installing and Removing Plug-in Units Chapter 4
.
9. Pull the unit forward (outward) approximately 3 in. (7.62 cm)
out of the MCC, using the handle provided at the lower left of
the unit and the tab in the upper right of the unit as finger holds.
You may need to reposition your hands as necessary to properly
support the unit while you are removing the unit from the MCC.
ATTENTION
Plug-in MCC units may be heavy or awkward to handle.
Use an assistant or a platform lift device if necessary to
help you handle the unit.
