Design Guidelines
Transport System Design
QuickStick HT User Manual 101
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Figure 3-29: MICS File Example (Continued)
<Motor> <!-- P2M2 -->
<Mac_addr>C0:6C:6D:E0:00:2A</Mac_addr> <!-- Motor MAC address -->
<IP_addr>10.14.2.2</IP_addr> <!-- Motor IP address -->
<Track_location>P2M2</Track_location> <!-- Track NC Path, Motor # -->
</Motor>
<Motor> <!-- P2M3 -->
<Mac_addr>C0:6C:6D:E0:00:2C</Mac_addr> <!-- Motor MAC address -->
<IP_addr>10.14.2.3</IP_addr> <!-- Motor IP address -->
<Track_location>P2M3</Track_location> <!-- Track NC Path, Motor # -->
</Motor>
<!-- PATH 3 -->
<Motor> <!-- P3M1 -->
<Mac_addr>C0:6C:6D:E0:00:50</Mac_addr> <!-- Motor MAC address -->
<IP_addr>10.14.3.1</IP_addr> <!-- Motor IP address -->
<Track_location>P3M1</Track_location> <!-- Track NC Path, Motor # -->
</Motor>
<Motor> <!-- P3M2 -->
<Mac_addr>C0:6C:6D:E0:00:2D</Mac_addr> <!-- Motor MAC address -->
<IP_addr>10.14.3.2</IP_addr> <!-- Motor IP address -->
<Track_location>P2M3</Track_location> <!-- Track NC Path, Motor # -->
</Motor>
<Motor> <!-- P3M3 -->
<Mac_addr>C0:6C:6D:E0:00:29</Mac_addr> <!-- Motor MAC address -->
<IP_addr>10.14.3.3</IP_addr> <!-- Motor IP address -->
<Track_location>P3M3</Track_location> <!-- Track NC Path, Motor # -->
</Motor>
</MICS_motor_data>
