Page #204 background image
Installation
Transport System Installation
204 MagneMotion
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Connector Kit Specifications
Table 5-5: Universal Feedback Connector Kit Wiring Requirements
Attribute Value
Cable diameter 6.5…11.9 mm (0.26…0.47 in.)
Screw terminal wire size 0.08…1.5 mm2 (28…16 AWG)
Recommended wire strip length 5 mm (0.2 in.) single conductor
Recommended torque
Mounting screws
Terminal screws
Clamp and cover screws
0.39 N•m (3.5 lb•in)
0.22…0.25 N•m (1.9…2.2 lb•in)
0.34 N•m (3.0 lb•in)
Kit contents
• Connector kit
• Parts bag containing:
- 1 cover screw, and 1 spare, #4-20, (0.375 in.)
- 2 clamp screws, and 1 spare, #4-40, (0.25 in.)
- 1 shield clamp
