Specifications and Site Requirements
Electrical Specifications
138 MagneMotion
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Custom Motor/QSMC Sense Cable
If making custom Stator Sense cables, follow these design specifications.
• Use a 6-wire Eurofast female connector (Turck WK 4.6T) at the stator end.
• Use a 6-wire Eurofast male connector (Turck RS 4.6T) at the motor controller end.
• Use stranded wire of the appropriate gauge for the length of the cable (see Table 4-8).
• Manufacturing best practices must be followed.
Table 4-8: Stator Sense Cable Wire Gauge Chart
Wire Gauge Max Cable Length
*
* Maximum cable length is based on power drop and
does not account for noise susceptibility.
20 AWG 45 m
22 AWG 30 m
24 AWG 15 m
26 AWG 10 m
NOTICE Modifications to the MMI motor to motor controller cables,
or using custom cables, violates the UL conditions of accept-
ability.
