Specifications and Site Requirements

Electrical Specifications

QuickStick HT User Manual 161

Rockwell Automation Publication MMI-UM007F-EN-P - September 2020

Table 4-42: QSHT 5700 Inverter Connector Pinout

1 U - (closest to back of drive)

2 V

3 W

4 GND - (closest to front of drive)
