Installation
Transport System Installation
QuickStick HT User Manual 193
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
motors at the ends of all paths that meet in a node must be made to the same node controller.
See the QuickStick Configurator User Manual, MMI-UM009, for more information about
nodes and paths.
Figure 5-7: QSHT Motor and QSMC RS-422 Communications Connections
NOTICE Modifications to the MMI motor to motor controller cables,
or using custom cables, violates the UL conditions of accept-
ability.
Sense Connector
Node
1/2 m QSHT
QSMC
Motor Controller
D
o
w
n
s
t
r
e
a
m
(typical)
Power Connector
(typical)
U
p
s
t
r
e
a
m
1m QSHT
RS-422 Cable
(typical)
Controller
Downstream
Upstream
Connection
Connection
QSMC-2
Motor Controller
Drive Cable
(typical)
Sense Cable
(typical)
To Next Page
