SECTION

IT

SERVICING

MAINTENANCE

MANUAL

ROCKWELL

COMMANDER

112/B/TC/TCA

AND

INSPECTION

INSPECTION

To

avoid

repetition

throughout

an

inspection,

general

points

to

be

checked

are

given

in

Figure

2-8.

Only

the

items

to

be

inspected

are

listed

and

details

as

to

how

to

check,

or

what to

check

for,

are

excluded.

Details

on how and what

to

check

for

are

specified

in

the

appropriate

sections

of

this

manual.

Some

item

s

are

optional

equipment

that

may

not

be

found

on

a

particular

airplane.

Check

FAA

Airworthiness

Direc-

tives

and

General

Aviation

Division

Service

Letters

for

compliance

at

the

time

specified

by

them.

INSPECTION CHECKLIST

MOVABLE PARTS

for:

lubrication,

servlCmg,

secur-

ityof

attachment,

binding,

excessive

wear,

safetying,

proper

operation,

proper

adjustment,

correct

travel,

cracked

fittings,

security

of

hinges,

defective

bearing,

cleanliness,

corrOSion,

deformation,

sealing

and

tensions.

FLUID LINES

AND

HOSES

for:

leaks,

cracks,

dents,

kinks,

chafing,

proper

radius,

security,

corrOSion,

deteriorations,

obstructions

and

foreign

matter.

METAL PARTS

for:

security

of

attachment,

cracks,

metal

distortion,

broken

spotwelds,

corrOSion,

con-

dition of

paint

and any

other

apparent

damage.

WIRING

for:

security,

chafing,

burning,

defective

insulation,

loose

or

broken

terminals,

heat

deterio-

ration

and

corroded

terminals.

BOLTS

IN

CRITICAL AREAS

for:

correct

torque

in

accordance

with

the

torque

values

given

in

the

chart

or

when

visual

inspection

indicates

the

need

for

a

torque

check.

FILTERS, SCREENS,

AND

FLUIDS

for:

cleanliness,

contamination

and/or

replacement

at

specified

inter-

vals.

AIRFRAME

MAINTENANCE

AIRFRAME SEALING

The

airframe

is

sealed

during

manufacture

of

the

various

subassemblies

and

again

after

airframe

com-

pletion. The follOWing

information

is

included

to

assist

in the

maintenance

and

repair

of

the

airframe

to obtain a

correct

and

lasting

seal

when

replacing

any

structural

parts.

SEALANT

AND

INSULATION MATERIALS.

The

following

is

a

list

of

sealants

and

insulation

materials

to

be

used

in

the

aircraft.

Products

Research

Co.

2-14

1005L

Class

B-1/2

(MIL-S-4383)

1221

Class

A-1/2

(MIL-S-7502)

1221

Class

A-2

(MIL-S-7502)

1403-G-B2

1422

Class

A-1/2

(MIL-S-8802)

1422

Class

A-2

(MIL-S-8802)

1422

Class

B-2

(MIL-S-8802)

1422

Class

B-4

(MIL-S-8802)

1435

Quick

Repair

Sealant

5000 White

Sealer

Dow

Corning

Corp.,

RTV-732,

24

hour

Coast

Pro-Seal

700,

72

hour,

(MIL-S-38249,

Type 1).

NOTE

Class

A-

indicates

brushable

material.

Class

B-

indicates

filleting

or

injection

material.

Dash

numbers

indicate

work

life.

Example:

A-2

indicates

a

brush-

able

material

having a

2-hour

maximum

work

life.

Prior

to

use,

all

sealants

are

to

be

stored

in a

refrig-

erator.

Two-

part

sealants

should

be

mixed

only in

the

quantity

required

for

a

specific

task.

Surplus

ad-

hesive

should

be

discarded

since

the

storage

life

of

mixed

sealants,

even

under

refrigeration,

is

very

limited.

The

two-part

sealants

have

a

definite

and

limited

work

life

after

being

mixed;

the

work

life

being

the

length

of

time

the

sealant

will

remain

in

a

workable

form

before

becoming

too

hard.

Before

mixing

the

sealant,

the

amount

needed

for

the

specific

job

should

be

estimated

and

only

that

amount

mixed.

Do

not

try

to

seal

an

area

so

large

that

the

job

cannot

be

finished

within

the

work

life, of

sealants.

By

using

these

simple

precautions

a

great

deal

of

time

and

sealant

may

be

saved.

CLEANING MATERIALS

AND

TOOLS.

The

following

is

a

list

of

cleaning

materials

and

tools

used

when

applying

sealants.

1.

Methyl

Ethyl

Ketone (MEK).

2.

Gauze

sponges;

Johnson

and

Johnson,

Finetex,

Leshner

industrial

wipers,

or

equivalent.

3.

Clean

rags.

4.

Pyles

sealing

gun,

Model

250-06

(using

dispos-

able

cartridges).

5.

Sealant

forming

tools-spatula

and

sealant

fair-

ing

tools.

6.

Inspection

mirror.

7. Solvent

dispenser.

SEALING PROCEDURES.

The

following

procedures

are

provided

to

enable

operators

to

obtain

successful

sealing

of

the

airframe

during

and

following

repairs.

Cleaning

Remove

grease,

oil,

dirt,

chips

and

all

foreign

ma-

terial

prior

to

cleaning.

The

success

of a good

seal

depends

on

the

thorough

cleaning

of

both

surfaces

of

the

affected

parts

to

be

sealed.

Cleaning

can

be

ac-

complished

using

expendable

gauze

sponges

or

a

clean

lint-free

cloth.

Scrub

both

surfaces

until

cloth

re-

mains

clean

after

wiping. Do not

use

an

excessive

amount

of

solvent.

For

the

final

cleaning,

wipe

sur-

faces

dry

with a

clean

dry

cloth

to

remove

any

film

left

by

the

evaporation

of

the

solvent.

The

area

cleaned

should

be

slightly

wider

than

the

width of

the

sealant

to

be

applied.

All

cleaning

solvent

should

be

removed

from

assembly

faying

surfaces

with

oil-free,

com-

pressed

air.

If any

primer

or

paint

is

removed

dur-

Change

4
