Roland JD-08 - Configuring the EQ (Equalizer)

Configuring the Settings of This Unit
48
Configuring the EQ (Equalizer)
Step
buttons
Parameter (as
displayed)
Value Explanation
[1]
Sľ
OFF
,
On
Turns the equalizer on/off.
[2]
Lo. F
20
–
999
(Hz),
1.00
–
16.00
(kHz)
Sets the center frequency of the low range.
[3]
Lo. G -24.0
–
24.0 (dB)
Adjusts the amount of boost/cut of the low-frequency
range.
[4]
Nid.F
20
–
999
(Hz),
1.00
–
16.00
(kHz)
Adjusts the amount of mid-frequency boost/cut.
[5]
Nid.q
0.5
–
16.0
Sets the width of the mid-frequency range. Higher values
make the width more narrow.
[6]
Nid.G
-24.0
–
24.0
(dB)
Adjusts the amount of boost/cut of the mid-frequency
range.
[7]
Hi. F
20
–
999
(Hz),
1.00
–
16.00
(kHz)
Sets the center frequency of the high range.
[8]
Hi. G -24.0
–
24.0 (dB)
Adjusts the amount of boost/cut of the high-frequency
range.
