Roland PNC-960 User Manual

9
3 Basic Operation
6
Feed out the length
of material to be cut.
7
Return the fed-out
material.
5
Press the SETUP
key.
To Perform Long Cutting
When performing cutting over a length of 1.5 m (60") or more, first feed out the required length of material. Then follow the
steps below to load the material.
Guide line
marks
25 mm
(1")
or more
2
4
3
1
Pull out the material from the roll and
pass it through the unit.
Use material that is wider by 50 mm (2") or more than
the width of the cutting to be performed.
Pull out the amount of
roll material to be used.
Make sure that the material
remains held by the pinch
rollers.
If the material does come
loose from the pinch rollers,
set it in place again.
Guide line
marks
25 mm
(1")
or more
