18
Recording
Connecting audio equipment
Using the SC-D70, not only microphone or guitar, but also the output from a MIDI
sound generator or audio device can be recorded via the audio input jacks or digital
input connector into your computer.
Here we will record stereo audio data (e.g., from the output of an audio device) into
your sequencer software.
Making connections to the audio input jacks
fig.22-03.e
1. Before you connect an audio device to the SC-D70, lower the level of the
audio input gain knob.
2. Connect the audio input jacks of the SC-D70 to the audio outputs of
another audio device (e.g., stereo set or CD player).
fig.22-04.e
1
SC-D70
R
L
OUTPUT
INPUT
Audio (Stereo set, CD player etc)
To Next Page
