MIDI Implementation
Parameter address map
(Model ID = 00H 20H)
This map indicates address, size, Data (range), Parameter, and Description of parameters
which can be transferred using “Data set 1 (DT1)”.
All the numbers of address, size, Data, and Default Value are indicated in 7-bit
Hexadecimal-form.
Addresses marked at “#” cannot be used as starting addresses.
■ Parameter Address Block
TD-8 (Model ID = 00H 20H)
+-----------------------------------------------------------------------+
| Start | |
| address | Description |
|-------------+---------------------------------------------------------|
| 00 00 00 00 | SETUP (Individual) *1-1|
|-------------+---------------------------------------------------------|
| 01 00 00 00 | DRUM KIT 1 (Individual) *1-2|
| : | : |
| 01 3F 00 00 | DRUM KIT 64 (Individual) *1-2|
|-------------+---------------------------------------------------------|
| 04 00 00 00 | USER PERCUSSION SET 1 (Individual) *1-3|
| 04 01 00 00 | USER PERCUSSION SET 2 (Individual) *1-3|
|-------------+---------------------------------------------------------|
| 10 00 00 00 | USER PATTERN & SONG (Bulk) *1-4|
|-------------+---------------------------------------------------------|
| 40 00 00 00 | SETUP (Bulk) *1-1|
|-------------+---------------------------------------------------------|
| 41 00 00 00 | DRUM KIT 1 (Bulk) *1-2|
| : | : |
| 41 3F 00 00 | DRUM KIT 64 (Bulk) *1-2|
|-------------+---------------------------------------------------------|
| 44 00 00 00 | USER PERCUSSION SET 1 (Bulk) *1-3|
| 44 01 00 00 | USER PERCUSSION SET 2 (Bulk) *1-3|
+-----------------------------------------------------------------------+
*1-1 SETUP
+-----------------------------------------------------------------------+
| Offset | |
| address | Description |
|-------------+---------------------------------------------------------|
| 00 00 00 | TRIGGER BANK 1 *1-1-1|
| 01 00 00 | TRIGGER BANK 2 *1-1-1|
| 02 00 00 | TRIGGER BANK 3 *1-1-1|
| 03 00 00 | TRIGGER BANK 4 *1-1-1|
|-------------+---------------------------------------------------------|
| 04 00 00 | TRIGGER BANK NUMBER *1-1-2|
|-------------+---------------------------------------------------------|
| 05 00 00 | HEAD TENSION ADJ *1-1-3|
|-------------+---------------------------------------------------------|
| 06 00 00 | MIDI *1-1-4|
|-------------+---------------------------------------------------------|
| 07 00 00 | PROGRAM CHANGE MAP *1-1-5|
|-------------+---------------------------------------------------------|
| 08 00 00 | OUTPUT ASSIGN *1-1-6|
|-------------+---------------------------------------------------------|
| 09 00 00 | CONTROL *1-1-7|
|-------------+---------------------------------------------------------|
| 0A 00 00 | MASTER TUNE *1-1-8|
|-------------+---------------------------------------------------------|
| 0B 00 00 | DRUM KIT CHAIN 1 *1-1-9|
| : | : |
| 0B 0F 00 | DRUM KIT CHAIN 16 *1-1-9|
+-----------------------------------------------------------------------+
*1-1-1 TRIGGER BANK
+-----------------------------------------------------------------------+
| Offset | |
| address | Description |
|-------------+---------------------------------------------------------|
| 00 00 | Pad parameters (1/KICK1) *1-1-1-1|
| 01 00 | Pad parameters (2/KICK2) *1-1-1-1|
| 02 00 | Pad parameters (3/SNARE) *1-1-1-1|
| 03 00 | Pad parameters (4/TOM1) *1-1-1-1|
| 04 00 | Pad parameters (5/TOM2) *1-1-1-1|
| 05 00 | Pad parameters (6/TOM3) *1-1-1-1|
| 06 00 | Pad parameters (7/HI-HAT) *1-1-1-1|
| 07 00 | Pad parameters (8/CRASH1) *1-1-1-1|
| 08 00 | Pad parameters (9/CRASH2) *1-1-1-1|
| 09 00 | Pad parameters (10/RIDE) *1-1-1-1|
| 0A 00 | Pad parameters (11/AUX1) *1-1-1-1|
| 0B 00 | Pad parameters (12/AUX2) *1-1-1-1|
+-----------------------------------------------------------------------+
*1-1-1-1 TRIGGER BANK (Pad parameters)
+-----------------------------------------------------------------------+
| Offset | | |
| address | Size | Description |
|-------------+-----------+---------------------------------------------|
| 00 | 000a aaaa | PAD TYPE 0 - 19 |
| | | (PD5,PD7,PD9,8 A,8 B,8RA,8RB,10A,10B, |
| | | 12A,12B,P 1,P 2,KD7,K 8,K12,K 1,K 2, |
| | | KIK,SNR,TOM,FLR) |
|-------------+-----------+---------------------------------------------|
| 01 | 0000 aaaa | RIM SHOT SENSITIVITY 0 - 15 |
| | | (OFF, 1 - 15) |
| | | (3/SNARE only) |
|-------------+-----------+---------------------------------------------|
| 02 | 0000 aaaa | CROSS STICK SENSITIVITY 0 - 15 |
| | | (1 - 16) |
| | | (3/SNARE only) |
|-------------+-----------+---------------------------------------------|
| 03 | 0000 aaaa | STICK | SENSITIVITY 0 - 15 |
| | | | (1 - 16) |
| 04 | 0000 aaaa | STICK | THRESHOLD 0 - 15 |
| 05 | 0000 0aaa | STICK | SENS CURVE 0 - 7 |
| | | | (LINEAR,EXP1,EXP2,LOG1,LOG2,SPLINE, |
| | | | LOUD1,LOUD2) |
|-------------+-----------+-------+-------------------------------------|
| 06 | 00aa aaaa | STICK | SCAN TIME 0 - 40 |
| | | | (0.0ms - 4.0ms, 0.1ms step) |
| 07 | 0000 aaaa | STICK | RETRIGGER CANCEL 0 - 15 |
| | | | (1 - 16) |
| 08 | 000a aaaa | STICK | MASK TIME 0 - 16 |
| | | | (0ms - 64ms, 4ms step) |
| 09 | 0000 aaaa | STICK | CROSSTALK 0 - 13 |
| | | | (OFF,20,25,30,35,40,45,50,55,60,65, |
| | | | 70,75,80) |
|-------------+-------------------+-------------------------------------|
| 0A | 0000 aaaa | BRUSH | SENSITIVITY 0 - 15 |
| | | | (1 - 16) |
| 0B | 0000 aaaa | BRUSH | THRESHOLD 0 - 15 |
| 0C | 0000 0aaa | BRUSH | SENS CURVE 0 - 7 |
| | | | (LINEAR,EXP1,EXP2,LOG1,LOG2,SPLINE, |
| | | | LOUD1,LOUD2) |
|-------------+-----------+-------+-------------------------------------|
| 0D | 00aa aaaa | BRUSH | SCAN TIME 0 - 40 |
| | | | (0.0ms - 4.0ms, 0.1ms step) |
| 0E | 0000 aaaa | BRUSH | RETRIGGER CANCEL 0 - 15 |
| | | | (1 - 16) |
| 0F | 000a aaaa | BRUSH | MASK TIME 0 - 16 |
| | | | (0ms - 64ms, 4ms step) |
| 10 | 0000 aaaa | BRUSH | CROSSTALK 0 - 13 |
| | | | (OFF,20,25,30,35,40,45,50,55,60,65, |
| | | | 70,75,80) |
|-------------+---------------------------------------------------------|
| Total size | 00 00 00 11 |
+-----------------------------------------------------------------------+
*1-1-2 TRIGGER BANK NUMBER
+-----------------------------------------------------------------------+
| Offset | | |
| address | Size | Description |
|-------------+-----------+---------------------------------------------|
| 00 00 | 0000 00aa | TRIGGER BANK NUMBER 0 - 3 |
| | | (1 - 4) |
|-------------+---------------------------------------------------------|
| Total size | 00 00 00 01 |
+-----------------------------------------------------------------------+
*1-1-3 HEAD TENSION ADJ
+-----------------------------------------------------------------------+
| Offset | | |
| address | Size | Description |
|-------------+-----------+---------------------------------------------|
| 00 00 | 0000 00aa | HEAD TENSION ADJUSTMENT 0 - 2 |
| | | (LOOSE,NORMAL,TIGHT) |
|-------------+---------------------------------------------------------|
| Total size | 00 00 00 01 |
+-----------------------------------------------------------------------+
*1-1-4 MIDI
+-----------------------------------------------------------------------+
| Offset | | |
| address | Size | Description |
|-------------+-----------+---------------------------------------------|
| 00 00 | 000a aaaa | TX/RX CHANNEL (PART1) 0 - 16 |
| | | (1 - 16,OFF) |
| 00 01 | 000a aaaa | TX/RX CHANNEL (PART2) 0 - 16 |
| | | (1 - 16,OFF) |
| 00 02 | 000a aaaa | TX/RX CHANNEL (PART3) 0 - 16 |
| | | (1 - 16,OFF) |
| 00 03 | 000a aaaa | TX/RX CHANNEL (PART4) 0 - 16 |
| | | (1 - 16,OFF) |
| 00 04 | 000a aaaa | TX/RX CHANNEL (PERC) 0 - 16 |
| | | (1 - 16,OFF) |
| 00 05 | 000a aaaa | TX/RX CHANNEL (KIT) 0 - 16 |
| | | (1 - 16,OFF) |
|-------------+-----------+---------------------------------------------|
| 00 06 | 0000 000a | NOTE CHASE 0 - 1 |
| | | (OFF,ON) |
| 00 07 | 0000 000a | LOCAL CONTROL 0 - 1 |
| | | (OFF,ON) |
| 00 08 | 0000 000a | SOFT THRU 0 - 1 |
| | | (OFF,ON) |
| 00 09 | 0000 000a | GM MODE 0 - 1 |
| | | (OFF,ON) |
| 00 0A | 0000 000a | RX GM ON 0 - 1 |
| | | (OFF,ON) |
| 00 0B | 0000 00aa | SYNC MODE 0 - 2 |
| | | (INT,EXT,REMOTE) |
| 00 0C | 0000 00aa | PEDAL DATA THIN 0 - 2 |
| | | (OFF,1,2) |
| 00 0D | 0000 0aaa | PEDAL CC 0 - 4 |
| | | (OFF,MOD(1),FOOT(4),GEN1(16),GEN2(17)) |
| 00 0E | 0000 00aa | ZONE CC 0 - 3 |
| | | (OFF,MOD(1),GEN1(16),GEN2(17)) |
| 00 0F | 0000 000a | CH10 PRIORITY 0 - 1 |
| | | (KIT,PERC) |
|-------------+---------------------------------------------------------|
| Total size | 00 00 00 10 |
+-----------------------------------------------------------------------+
*1-1-5 PROGRAM CHANGE MAP
+-----------------------------------------------------------------------+
| Offset | | |
| address | Size | Description |
|-------------+-----------+---------------------------------------------|
| 00 00 | 0000 000a | PROGRAM CHANGE RX SW 0 - 1 |
| | | (OFF,ON) |
| 00 01 | 0000 000a | PROGRAM CHANGE TX SW 0 - 1 |
| | | (OFF,ON) |
|-------------+-----------+---------------------------------------------|
| 00 02 | 0aaa aaaa | PROGRAM CHANGE (DRUM KIT 1) 0 - 127 |
| | | (1 - 128) |
| : | : | : |
