Rosco Maximizer 2B User Manual

9
9-15
Schematics
Rosco Maximizer 2B Asphalt Distributor
Return to
Last Viewed
Figure 9-7
Harness, Spraybar 1’ Control LH
12.00
4.00
43.00
10.00
10.00
8.00
5.00
22.00
8.00
BLUE
BROWN WHT/BLK WHT/BLK GRAY
BLACK PINK
5.00
BLACK GRN/WHT
4.00
(7) (7)
SEE CHART
100
100
100
100
123.00
1.00
1.00
1.00
WHT/BLK GROUND
IN REAR VALVE BOX
BLK/YEL RUNS TO TERM
#87a OF WINGFOLD RELAY
IN REAR VALVE BOX
OR GREEN WIRE
DO NOT BREAK RED
3.00 3.00 3.00 3.00 3.00
BLK/YEL BLACK
3.00
100
10023
Item
Description
Qty
Part No.
Parts list
88
28
93
40
23
40
22
23
74
74
7371
7270
35
36
34333129
Part No.Item
Description
Parts list
Qty
16 33271-17 17.00 WIRE,16 GA,WHITE/BLACK STRIPE
22 33602 2.00 CONN,BUTT,16-14 GA
23 36348 6.00 TERM,PUSH-ON,.25,M,18-14,SLV
28 36118-2 1.00 TERM,CRIMP,16-14 GA
29 37229 1.00 CONN HOUSING,CAP,8 WIRE
31 37284 7.00 TERM PIN METRIC PACK 150 SERIE
33 37286 7.00 SEAL,CABLE,METRI PACK,150 S
34 37287 1.00 PLUG,CAVITY,METRI PACK,150 S
35 37290 1.00 GROMMET,.50IDX.81HOLE
36 37291 5.00 GROMMET,.69IDX.81HOLE
40 38520 5.50 LOOM,SPLIT,CONVOLTD,.35,NYLON
59 33271-1 3.00 WIRE,16 GA,BLACK
70 36162 1.00 CONNECTOR,SEALED,SHROUD,6-PIN
71 36163 1.00 CONNECTOR,SEALED,TOWER,6-PIN
72 36164 6.00 TERM,SEALED CONN,16-14 GA,MALE
73 36165 6.00 TERM,SEALED CONN,16-14 GA,FEM
74 36166 12.00 SEAL,CABLE,18-16 GA
75 33271-0 12.00 WIRE,16 GA,GRAY
76 33271-10 15.00 WIRE,16 GA,GREEN/WHITE STRIPE
77 33271-11 12.00 WIRE,16 GA,BLUE
78 33271-12 16.00 WIRE,16 GA,RED/BLACK STRIPE
79 33271-13 18.00 WIRE,16 GA,BLACK/YELLOW STRIPE
80 33271-2 11.50 WIRE,16 GA,YELLOW
81 33271-3 11.00 WIRE,16 GA,BROWN
82 33271-4 23.00 WIRE,16 GA,GREEN
83 33271-5 16.00 WIRE,16 GA,WHITE
84 33271-6 16.00 WIRE,16 GA,ORANGE
85 33271-7 23.00 WIRE,16 GA,RED
86 33271-8 14.00 WIRE,16 GA,PINK
87 33271-9 16.00 WIRE,16 GA,PURPLE
88 38428 15.25 LOOM,SPLIT,CONVOLTD,.50,NYLON
93 33607 1.00 TERM,RING,16-14 GA,.250 STUD
100 36349 6.00 TERM,PUSH-ON,.25,FEM,18-14,SLV
23
23
23
DO NOT ASSEMBLE PINS INTO CONNECTORS ITEM 70 AND 71,
LEAVE ITEMS 70 AND 71 LOOSE UNTIL ASSEMBLED ON THE MACHINE
36
36
INSTALL GROMMETS BEFORE
INSTALLING END CONNECTORS
ITEMS 4O AND 88 ARE NYLON
LOOM OR HIGH TEMPERATURE
F E D C B A
YELLOW
WHT/BLK
WHT/BLK
F E D C B A
28292-02 HARNESS,SPRAYBAR,1' CONT,LH
A B C D
WIRING FOR ITEM 29
SOCKET
D D
5' 3".375
15' 7".500
LENGTHSIZE
LOOM
PURPLE
GREEN
RED
E
F
15' 11"
14' 10"
12' 9"
GRAY
PINK
GRN/WHT
E
F
LH WIRE HARNESS
WIRING FOR ITEM 70
WIRING FOR ITEM 71
LENGTH PIN WIRE
16' 0"
FEET
RED/BLK
COLOR
WHITE
ORANGE
A
B
C
LENGTH PIN WIRE
11' 10"
11' 9"
12' 8"
FEET
BLUE
COLOR
YELLOW
BROWN
A
B
C
D
PLUG
H
BLACK
ORANGE
RED/BLK
WHITE
G
F
E
WIRE
PURPLE
GREEN
RED
C
B
A
COLOR
16' 0"
16' 0"
16' 0"
16' 0"
16' 0"
