Rosco Maximizer 2B - Outside Overview (Continued)

5-2 Rosco Maximizer 2B Asphalt Distributor
Component Location
Outside Overview
1
2
6
3
4
517
7
8
2
12
13
14
9
10
11
15
16
II
II
Main Dash Panel
Figure 5-1
1 - Hydraulic Pump
2 - Tank Capacity Indicator
3 - Asphalt Tank
4 - Top Opening
5 - Hydraulic Tank
6 - GPS Speed Sensor
7 - Diesel Fuel Tank
8 - Thermometers
