Rosco Maximizer 2B User Manual

4-6
Rosco Maximizer 2B Asphalt Distributor
Specications
Table 4-1. Tank Specication Table
ITEM SPECIFICATION
Tank Capacity
1000 U.S. gallons (3,785 L) to 4000 U.S. gallons (15,142 L) with overage for expansion.
Tank Meets all applicable Federal DOT tank regulations. Elliptical shape. 10 gauge (3 mm)
shell and 7 gauge (4.5 mm) at heads, anged reinforced and welded to shell inside & and
outside of tank. All seams electrically welded.
Shell 10 gauge, elliptical shape shell. 7 gauge at heads, ange reinforced and electrically
welded to shell inside and outside of tank.
Thermometers Armored pencil inspector’s type 50° F to 500° F (10° C to 260° C) and 5 inch (127 mm) dial
type 50° F to 500° F (10° C to 260° C) mounted on front left side of tank in pipe well. Tank
temperature sensor, located at rear of tank, displayed on color display of in-cab controller.
Full Surge Plates 10 gauge (3 mm) steel with staggered openings.
Insulation 2 inch (51 mm) rock wool with spacers to prevent compression, and clips to secure
position of insulation. Weatherproof aluminum jacket.
Top Opening
22 inch (558 mm) diameter with weather tight and safety relieving cover. Inside splash
guards, 3 inch (76 mm) diameter, steel measuring stick, basket type strainer, overow pipe,
and tank vent.
Sump 8 inch (203 mm) diameter at rear of tank with 4 inch (102 mm) clean-cut plug. Suction line
from pump includes tank cut-off valve.
Heating System Double ue with 8 inch (203 mm) inside diameter tubing.
Exhaust Stack
Stainless steel with rain cover.
Burners Dual diesel red burner with electronic ignition and heat limit controls. Dual, U-type high-
temperature ue pipe running the length of the tank.
Asphalt Pump
Viking 400 GPM (1514 LPM) capacity, rotary gear pump with built in relief valve for safety.
Located at rear of unit with suction piping to tank sump. Driven by low-speed, high-torque,
xed displacement hydraulic motor.
Distributing Lines High-temperature, exible metal hoses.
Clean Out Connection to asphalt pump for clean-out of pump and piping. 25 gallon (94.6 L) ush tank.
Spray System
12 foot (3.7 m) full circulating bar with two 4 foot (1.2 m) center sections and two 2 foot (0.6
m) cab control folding wings. Power lift and shift of spraybar. Exclusive two-way safety
breakaway system provides protection against damage when an obstruction is hit while
traveling either forward or reverse.
Nozzles and Valves Brass, slotted nozzles, with non-clogging, quick-disconnect valves. Allows the operator to
change spray widths in 4 inch (10.16 cm) increments.
