Rosco Maximizer 2B Asphalt Distributor 10-5
Illustrated Parts List (IPL)
Platform Installation, w/o Handrail Parts List
Item
No. Part Number Qty. Description Remarks
1002456 1 Platform Installation, W/O Handrail
1 20841 1
Hose, Flex, Met, 3.00 X 13.94
2 1002455 1 Rear Platform & Piping Assy, 96
3 34981 1 Gasket, 3” Flange
4 34983 3 Gasket, 4” Flange
5 71640 4
CSHH, .625-11 X2.50, Gr5 71678
6 71643 4 CSHH, .750-10 X 1.75, Gr5
7 80042 4 Nut, Hex, .625-11
8 80146 4 Washer, Type A Plain, .625
9 80162 32 Washer, Lock, .375
10 80166 4 Washer, Lock, .625
11 80168 4 Washer, Lock, .750
12 80219 32 CSHH, .375-16 X .75, Gr5
13 911 1 Gasket, 3.00 Companion Flange
14 80038 8 Nut, Hex, .375-16
15 20841 1 Hose, 3.00 x 13.94 Metal Flex
16 1003146 1 Valve, Solenoid, 1/2" Ball
