Rosco Maximizer 2B Asphalt Distributor 10-21
Illustrated Parts List (IPL)
Flex Hose Assembly Parts List
Item
No. Part Number Qty. Description Remarks
22566SRV 1 Flex Hose Assembly
1 1284 2
Spr, Tubing, .12 Dia X 8, SST
2 17951 Clamp, Hose, 2.375 ID, A/R
3 22593-12BR 1 Hose, Flex, LH, Bend Restrictor
4 22594-12BR 1 Hose, Flex, RH, Bend Restrictor
5 34981 2 Gasket, 3" Flange
6 37253 1
Hoes, 2.00ID X 80, Flex, Metal, FEM
7 80038 16 Nut, Hex, .375-16
8 80042 8 Nut, Hex, .625-11
9 80142 16 Washer, Type A Plain, .375
10 80146 8 Washer, Type A Plain, .625
11 80162 16 Washer, Split Lock, .375
12 80166 8 Washer, Lock, .625
13 80224 18 CSHH, .375-16X1.25, GR5
14 71640 8 CSHH, .625-11X2.50, GR571678
15 80352 2 Nut, Flexloc, .375-16, Full, LT
16 911 2 Gasket, 3.00 Companion Flange
