Rosco Maximizer 2B Asphalt Distributor 10-47
Illustrated Parts List (IPL)
Hydraulic Reservoir Parts List
Item
No. Part Number Qty. Description Remarks
22490SRV 1 Hydraulic Reservoir
1 22489 1 Reservoir, 20 Gal
2 22750 1 Reservoir, Cleanout Cover
3 35254 1 Pipe Plug, Mag, 06Mp, Sq Hd
4 36343 1
Switch, Temp, 210 Deg F.,-08Mp
5 500070 1 Gauge, Hyd Oil Level/Temp
6 71627 4
CSHH, .500-13 X 1.50, Gr5
7 80144 8 Washer, Flat, Uss, .500
8 80160 12 Washer, Lock, .250
9 80354 4 Nut, Flexloc, .500-13, Full, Lt
10 80192 12 CSHH, .250-20 X. 75, Gr5
11 37680 1 Filler, Hyd Fluid, 10 Psi
12 99299 1
Pipe Plug, 2.00Mp, Skt Hd, Mi
13 81161 12 Washer, Weather Seal, #10
14 99463 1
Pipe, Bush, 1.25 Mp-12Fp, Mi
