Rosco Maximizer 2B Asphalt Distributor 10-57
Illustrated Parts List (IPL)
Parts List
Item
No. Part Number Qty. Description Remarks
22522 1 Spraybar Assembly
1 19105 36 EZ-1 Spray Valve Assembly
2 19720 1 Rod, Breakaway
3 22499 1 Cap, RH, Spraybar End
4 22515 1 Cap, LH, Spraybar End
5 24691 1 Spraybar Wldmt, Ctr, LH
6 24690 1 Spraybar Wldmt, Ctr, RH
7 24149 1 Spraybar Wldmt, Wing, LH
8 24150 1 Spraybar Wldmt, Wing, RH
9 22597 1 Breakaway W/Chain
10 32918 36 Nozzle, #1 (Standard)
11 35881 72 Gasket, Asphalt Spray Valve
12 37185 2 Gasket, Spraybar End
13 6527 8
Cshfhs, .500-13 X 1.25, Whizlock
14 71617 3 Cshh, .375-16 X 5.00, Gr5
15 80038 2 Nut, Hex, .375-16
16 80098 36 Nut, Hex, Jam, 1.000-12
17 80142 7 Washer, Type A Plain, .375
18 80317 2 Set S, Sq, Kcup, .375-16 X 1.50
19 80352 4 Nut, Flexloc, .375-16, Full, Lt
20 80706 36 Washer, Sae Plain, 1.000
21 8367 2 Casting, Cap, Sump
22 8393 4 Washer
23 8394 10
Gasket, Fold Sect, .12 X 3.38 x 3.75
24 846082155 3 Spring, 1.18OD, 1.15Lg, .225 Wire
