Rosco Maximizer 2B - Page 263

10
Rosco Maximizer 2B Asphalt Distributor 10-85
Illustrated Parts List (IPL)
Burner Covers & Flue Liners Parts List
Item
No. Part Number Qty. Description Remarks
-1 27848 2 Flue Liner W/M, Diesel Burner, Sst
-101 22781 1 Flange, Flue Liner
-102 27849 2 Flue Liner Half, Hex
-2 22475SRV 1 Burner Cover, Double Flue Not Shown
-201 22469 1 Mtg Plate, Bnr Cover, Dbl Flue
-202 22472 1 Burner Cover W/M, Double Flue
-3 38662S2SRV 2 Filter Kit, Double Burner
-301 31971 1 Fitt, 90, 04MP-04HB, Crimped
-302 33280 1 Fitt, Str, 06MP-04HB, Push-On
-303 38662 1 Filter Assembly, Fuel Oil
-304 99448 1 Pipe, Bush, 06MP-04FP, Stl
-305 99450 1 Pipe, Bush, 08MP-06FM, Mi
-306 99537 1 Pipe, Plug08MP, Sq Head
-307 99568 1 Pipe, Tee, 06FP, Mi
-308 99569 1 Pipe, Tee, 08FP, Mi
-309 99638 2
Pipe, Nipple, .375 X Close
