Rosco Maximizer 2B Asphalt Distributor 10-143
Illustrated Parts List (IPL)
Washdown System Parts List
Item
No. Part Number Qty. Description Remarks
23223SRV 1 Washdown System
3 32881 1 Hose, 04 X 300, 04FPX-04RE, 350
4 33163 2
Clamp, Hose, .50-.91, Worm, #08
6 33328 1 Fitt, 90 08MP-08HB, Crimped
-7 33596 4
Tie Wrap, .188 X 7.5
9 33602 2 Conn, Butt, 16-14 Ga
10 985043 1 Pump, Water/Fuel, Diaphragm, 12V
-1001 984385 1 Port Kit, 08 Threaded
19 36206 1 Decal, Washdown Pump Buzzer
20 36208 1 Buzzer, 12 VDC, Continuous Tone
21 36926 1 Strainer, Lqd, 100Mesh, Nyl, 08FP
23 986227 1 Reel, W/Hose, Spraydown
-2301 80164 4
Washer, Lock, .500
-2302 80186 2 CSHH, .500-13 X 1.75, Gr5
-2303 80354 2 Nut, Flexloc, .500-13 ,Full, Lt
-2304 920200 1 Reel, W/Hose, Spray Down
-2305 920220 1 Nozzle, Fuel Washdown, W/Handle
-23051 901210A 1 Nozzle, Fuel,Washdown (Nozzle Only)
-23052 984948 1 Handle,Fuel, Washdown (Handle Only)
-2306 986226 1 Mount Assy, Hose Reel
24 6298 1 Fitt, Str 04MP-09MPF, LH LP Gas
25 6352 5 Hose, 08, Push-On, 250
26 986274 1 Holster Assy, Nozzle, Washdown
-2601 80963 1
Washer, Flat, Sae, .312
-2602 986272 1 Holster Tube, Washdown System
-2603 986273 1 Tab, Washdown Holster
30 80141 4
Washer, Flat, Uss, .313
31 80207 2 CSHH, .312-18 X .75, Gr5
32 80351 2 Nut, Flexloc, .312-18, Full, Lt
35 80924 4 Nut, Flexloc, #10-24, Full, Lt
36 80995 8 Washer, Type A Plain, #10
37 80997 4
Mach Scr, Ph, #10-24 X 2.00
38 99503 1 Pipe, 45, 04FP, Mi
39 99512 1 Pipe, 90, 08FP, Mi
40 99526 1 Pipe, 90, 08MP-08FP, Mi
41 99569 1 Pipe, Tee, 08FP, Mi
42 99596 1 Pipe, Nipple, 08 X Close
43 99636 1
Nipple, 04 X 11.00, Std
