Rosco Maximizer 2B Asphalt Distributor 10-147
Illustrated Parts List (IPL)
Return Line Valve Parts List
Item
No. Part Number Qty. Description Remarks
28725 1 Return Line Valve
-1 20841 1
Hose, Flex, Met, 3.00 X 13.94
2 28184SRV 1 Valve Assy, Tank, 3.00
3 28694 1 Hose Wldmt, Flex, 3.0 X 9.34
5 33115 2 Fitt, 45 04MJ-04MP
6 34981 1 Gasket, 3” Flange
7 38816-01 1 Valve, Sol, Air, 3 Cv
8 72649 2 Fitt, Str 04MJ-02MP
9 5347 16 Hose, 04, Push-On, Low Pressure
10 70957 4 Fitt, Str 04FJX-04HB, Push-On
11 99448 2 Pipe, Bush, 06MP-04FP, Stl
13 80038 8
Nut, Hex, .375-16
14 80162 8 Washer, Lock, .375
15 80221 8 CSHH, .375-16 X 1.00, Gr5
16 35040 1 Cyl, Air, 3.0 x 4.0
