Rosco Maximizer 2B Asphalt Distributor
5-9
Component Location
ITEM NO. CONTROL NAME FUNCTION
6
1 ft. Spray Nozzle
Activation - Right Bar
There are six 1 ft. spray nozzle activation switches on the control panel
corresponding to the nozzles on the right 6 ft. of spraybar. These switches
are positioned on the In-Cab Control Box in relationship to the 1 foot
sections along that 6 ft. length of the spraybar. Once activated (switch
down); the nozzles will spray asphalt when the Spraybar Master Switch
(Figure 5-2,4) is moved to the SPRAY position.
7 Optional Spraybar
Extension Activation
Control
When the spraybar extension option is used there are additional nozzle
activation switches added to the In Cab Control Box. These switches are
used to activate spray nozzles in 1 ft. increments on the spraybar extensions.
These switches are positioned on the In-Cab Control Box to correspond
with each 1 foot section along the spraybar extensions. Once activated
(switch down); the nozzles will spray asphalt when the Spraybar Master
Switch (4) is moved to the SPRAY position.
8 Left Spraybar Wing
Fold / Unfold
This switch is a momentary switch which hydraulically moves the left
spraybar wing to the horizontal position (switch down) for spraying and to
the vertical position (switch up) for travel. The spraybar wing moves in the
direction of the switch as the operator holds it in place. Once released the
switch springs to the center position and spraybar wing movement stops.
There is a magnetic switch in the spraybar wing which prevents spraying
from the wing when it is in the vertical position.
9 Right Spraybar Wing
Fold / Unfold
This switch is a momentary switch which hydraulically moves the right
spraybar wing to the horizontal position (switch down) for spraying and to
the vertical position (switch up) for travel. The spraybar wing moves in the
direction of the switch as the operator holds it in place. Once released the
switch springs to the center position and spraybar wing movement stops.
There is a magnetic switch in the spraybar wing which prevents spraying
from the wing when it is in the vertical position.
10 Spraybar Shift This is a momentary switch which allows the operator to shift the spraybar
left or right for precise alignment of the asphalt spray pattern. The spraybar
will move in the direction of the switch (left or right) as the operator holds
it in place. Once released the switch springs to the center position and all
movement stops. The spraybar will shift left or right a maximum of 18” in
either direction.
11 Spraybar Raise / Lower
Switch
This is a momentary switch which allows the operator to raise or lower the
spraybar to achieve optimum results during spraying. The spraybar will
move in the direction of the switch (up or down) as the operator holds it
in place. Once released the switch springs to the center position and all
movement stops. Typical spraying height is between 9” and 11” from the
bottom of the nozzles to the road surface. Set height to assure complete
triple spray fan coverage from the nozzles.
12 Soft Keys The color display on the In-Cab Controller is surrounded by 8 buttons
labeled 1 thru 8. These buttons are soft keys meaning they function
according to the labels next to them on the color display. The screen will
indicate the function of each button depending on the screen displayed at
the time.
13 ESC Button Use this button to cancel a function or escape from a screen.
Table 5-2. Main In-Cab Control Panel (continued)
