Rosco Maximizer 2B Asphalt Distributor
5-17
Component Location
Table 5-5. Run Screen
ITEM NO. CONTROL NAME FUNCTION
1 Mode Selection Screen (Button 1) Calls up the Mode Selection Screen to select and set 1 of 8 modes
of distributor operation. See Figure 5-6.
2 AUTO / MANUAL
Selection
(Button 2) Operator can select Auto or Manual Control of the distributor.
Auto Control - Asphalt Pump speed is automatically controlled through
the Plus 1 Controller using a PID rhythm. The set application rate is
automatically held constant regardless of changes in spraybar width or
vehicle speed. Auto control can be activated when operating the distributor
in Spray or Bar Circulate mode. All other modes of operation will default to
Manual control with the exception of Auto Cleanout mode. Auto Cleanout
mode automatically sets the speed and direction of the Asphalt Pump
according to a programmed sequence in the Plus 1 Controller.
Manual Control - Operator has complete control of the Asphalt Pump speed
and direction through the speed pots on the In-Cab Control Box or the Right
Rear Fender Control. The operator can select one or the other by toggling
the Front or Rear priority selection (Button 3). The Run Screen display
indicates the asphalt ow rate so the operator can judge the Asphalt Pump
speed adjustments that need to be made.
3 FRONT / REAR Control
Priority Selection
(Button 3) Denes either In-Cab Control or Rear Fender Control of the
spraybar hydraulic functions and asphalt pump speed/direction.
4 Setup Parameters (Button 4) Denes operating parameters.
5 Inactive Button (Button 5) is inactive -Not used
6 Memory (1 of 12) (Button 6) Pre dened distributor application rates stored in memory.
7 Application Rate
(Button 7) Sets the application rate (gal/sq.yd.).
8 Error Fault Screen (Button 8) Used for help troubleshooting the distributor when an error
occurs. Used as a diagnostic tool if a problem or breakdown should occur.
9 Flow Rate Dial gpm
(Lpm)
Real time measurement of asphalt owing through the asphalt pump.
10 Distributor Speed Dial
fpm (mpm)
Real time measurement of distributor ground speed.
11 Asphalt Tank
Temperature °F (°C)
Real time measurement of asphalt temperature in the tank.
12 Current Mode Indicator Current Distributor Operating Mode.
13 Appl. Rate gal/sq. yd. (L/
sq.m)
Display of set application rate.
14 Bar Length ft.-in. (m-cm) Real time display showing the spray width from 4” to 24’ in 4” increments
(10cm - 7.3m in 10cm increments).
