Rosemount 3491 - Page 105

Reference Manual
00809-0100-4841, Rev. AA
May 2007
4-73
Rosemount 3490 Series
Table 4-16. Primary Display
Parameter Selection
P570/1/2 Options Parameters
None (Nothing selected)
D800-PV MCU PV value
D801-SV MCU SV value
D802-TV MCU TV value
D803-FV MCU FV value
D805-%mA Out Percentage of current output (4-20mA span)
D806-mA Output Actual current output
D809-RoC Rate of Change of PV value
D828-Totaliser Totaliser value (model 3491)
D828-Totaliser 1 Totaliser 1 value (models 3492 and 3493)
D829-Totaliser 2 Totaliser 2 value (models 3492 and 3493)
D821-RL1 RTime Running time for relay RL1 if energised
D822-RL2 RTime Running time for relay RL2 if energised
D823-RL3 RTime Running time for relay RL3 if energised
D824-RL4 RTime Running time for relay RL4 if energised
D825-RL5 RTime Running time for relay RL5 if energised
D840-mA Input Actual current input
D844-Internal C Temperature of 3490 Series Control Unit
D846 Logging memory remaining
D900-PV In Transmitter PV (Primary Variable)
D901-SV In Transmitter SV (Secondary Variable)
D902-TV In Transmitter TV (Tertiary Variable)
D903-FV In Transmitter FV (Fourth Variable)
P240-Descript Free-form description
(1)
(1) Parameter is in menu: SETUP / [MCU CONTROL UNIT /] Duty(Mode)
P241-Message Free-form message
(1)
P242-Tag Free-form tag name
(1)
P730-Date Date
P731-Time Time of day
Bargraph Bar graph of 4-20mA output of 3490 - for lower display only
