Reference Manual
00809-0100-4841, Rev. AA
May 2007
Rosemount 3490 Series
C-10
MONITOR
(1)
READINGS VARIABLES D900 Primary Variable As P012 - - - - - -
D901 Level (SV)
(2)
------
D902 Distance (TV)
(2)
------
D903 Transducer Temperature °C or °F- - - - - -
CURRENT D906 Current Output mA - - - - - -
D905 % Current Output % - - - - - -
D908 Relay Status
(3)
-------
DIAGNOSTICS
D910 Distance To Target
(2)
------
D911 Echo Size % - - - - - -
D912 Echo Success Rate % - - - - - -
D913 Target Echoes - - - - - - -
D914 Speed Of Sound (B.U.)/s - - - - - -
D915 Temperature SoS calc °C or °F- - - - - -
OPERATION D916 Transducer Frequency kHz - - - - - -
D917 Threshold in Use % - - - - - -
D918 Pulses In Use - - - - - - -
D919 Transmit Power - - - - - - -
STATUS D991 Device Status Group 1 - - - - - - -
D992 Device Status Group 2 - - - - - - -
D993 Device Status Group 3 - - - - - - -
D994 Device Status Group 4 - - - - - - -
D995 Device Status Group 5 - - - - - - -
D996 Device Status Group 6 - - - - - - -
HISTORY P003 Date ddmmyy - - - - - -
P046 Maximum Temperature °C 505050505050
P047 Minimum Temperature °C -10 -10 -10 -10 -10 -10
(1) Selecting this menu presents a SELECT INSTRUMENT screen if a HART transmitter is assigned to a Current Input channel. Select TRANSMITTER tag to see Menu Level 2 options.
(2) Units are the same as Base Units selection.
(3) Available on model 3102 only.
Param
ID
3102 3105
Menu Level 1 Menu Level 2 Menu Level 3 Menu Level 4 Parameter Units m ft In m ft in
