Rosemount 3491 - Page 64

Reference Manual
00809-0100-4841, Rev. AA
May 2007
Rosemount 3490 Series
4-32
Figure 4-23. P115 = 3490
Plotted Profile for "Flume (3/2)"
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
0.0
Y
X
Normalised units (range 0 to 1)
P115 = Plotted Profile for “Flume (3/2)”
