Rosslare AC Series User Manual

Technical Specifications
AC-x32 Series Installation and Programming Manual 11
Environmental Characteristics
Operating Temp. Range
-31°C to 63°C (-25°F to 145°F )
Operating Humidity Range
0 to 95% (non-condensing)
Physical Characteristics
Dimensions
(Length x Width x Depth)
AC-B32: 92 x 92 x 24 mm
(3.6 x 3.6 x 0.9 in.)
AC-C32: 130 x 42 x 18 mm
(5.1 x 1.7 x 0.7 in.)
AC-D32: 122 x 75 x 24 mm
(4.8 x 3.0 x 0.9 in.)
Weight
AC-B32: 124 g (4.4 oz)
AC-C32: 55 g (1.9 oz)
AC-D32: 115 g (4.1 oz)

Rosslare AC Series Specifications

General

Operating Voltage	12VDC
Input Voltage	12VDC
Communication	RS-485, TCP/IP
Output Voltage	12V DC
Enclosure Rating	IP65
Type	Access Control Unit
