Rotex RPS4 User Manual

34
FA ROTEX Solaris RPS4 - 06/2015
7 x Faults and malfunctions
7 Faults and malfunctions
7.1 Display of events
Using the menu path: "Selection 2/2" -> "System" -> "Event
memory" and, after entering the technician password
(see section 6.3.4 and fig. 6-7), any events that occur during op-
eration can be displayed. The Solaris R4 controller has a simple
fault diagnosis system for this purpose. The events memory
stores nature and time of the event. The event is displayed in
clear text and using a code, the time since the start of the event
is displayed in hours. Starting with the most recent event, you can
leaf through the individual events by means of the Info key.
If the parameter "delete" is shown in the menu item:
"Selection 2/2" -> "System" -> "Event memory" is set to "yes", all
events are deleted. Deletion of individual events is not possible.
An overview of possible entries in the event memory is given in
tab. 7-1.
Event
code
Plain text
display
Description Status
display
(flashing)
Lamp
(flashing)
Consequence
0 Collector
Collector sensor: Short-circuited or
open
KTK
Long-term switch-off of P
S
1
Return
flow
Return flow sensor: Short-circuited or
open
RTR
2
Storage
cylinder
Storage cylinder sensor: Short-cir-
cuited or open
STS
3 Flow FlowSensor: Short-circuited or open D
Operation without FlowSensor
4 Inflow FlowSensor: Short-circuited or open V
5 A/D Internal A/D converter fault G
Long-term switch-off of P
S
6 Supply
Internal equipment fault of the supply
voltage
G
7 Reference
Internal equipment fault of the refer-
ence voltage
G
8 Reset Overall reset was carried out
Parameters to factory settings, calculated
values and event entries deleted
(see chapter 6.2.10), equipment re-start
12 Start flow
Minimum flow rate V1 (see tab. 6-1)
not achieved in the start phase after
expiry of "Time P2" (description
see chapter 6.2.1 and 6.2.12)
W
Switch-off of P
S
for 2 h, then ready for oper-
ation again or status "F"
FTV
Long-term switch-off of P
S
, if an event arises
3x in a row without intermediate successful
start.
13
TS >
Tsmax
Storage tank maximum temperature
("TS max") exceeded (description
see chapter 6.2.1 and 7.2)
TS
Temporary switch-off of P
S
14 TR >> TS
T
R
- T
S
> 10 K and T
R
> 40 °C
(description see chapter 7.2)
TR
15
TK > TK
perm
Permitted solar panel maximum tem-
perature ("TK perm") exceeded -
(description see chapter 6.2.1 and
7.2)
TK
16 Interrupt
Flow breakaway during operating
phase detected (V < V2,
see chapter 6.2.9 and tab. 6-1)
Temporary switch-off of P
S
(minimum for sta-
bilisation time), blocking of current pump
modulation stage, and the one below, refilling
by P
S
for "Time P2" at next switch-on condi-
tion.
202
P-on
Reset
Switching on
Restart, all parameter settings and info
parameters remain, automatically blocked
pump output stages are released again.
204 Brown-out
Reset caused by prohibited reduction
in the mains voltage
Restart in accordance with Code 202.
205 Watchdog
Reset caused by external interference
influences (e.g. over-voltages caused
by thunderstorms)
Restart in accordance with Code 202.
Tab. 7-1 Event storage
