FA ROTEX Solaris RPS4 - 06/2015
8 x Hydraulic system connection
8.2 Connection of a pressure solar panel
system
If the structural conditions do not permit mounting the solar
panels above the storage tank, or if the connecting line cannot be
installed with a continuous gradient between the solar panel and
the storage tank, you cannot use the depressurised ROTEX
solar system (DrainBack) and thus the Control and pump unit
RPS4.
Instead, the heating system can be executed with the ROTEX
solar pressure system. The following solar components can be
used equally in both systems:
Ɣ Solaris high-performance flat solar panels V21P, V26P, H26P
Ɣ Solaris on-roof, flat-roof and in-roof mounting packages
Ɣ Solaris hot water storage tank
Other system components must only be used under system-spe-
cific conditions.
Short name. Meaning
1 Cold water distribution network
2 Hot water distribution network
3 Heating flow
4 Heating return flow
5 Mixing circuit
6 Circulation
7 Check valve, return valve
7a Non return valves
8 Solar circuit
9 Gas pipe (coolant)
10 Fluid pipe (coolant)
11 Storage tank flow
12 Storage tank return flow
3UV1 3-way switch valve (DHW)
3UV2 3-way switch valve (cooling)
3UV3 3-way switch valve (heating support)
3UVB1
3-way switch valve (heating, internal circuit regu-
lated)
3UV DHW
3-way switch valve (DHW + heating support reg-
ulated)
A1 A1 oil or gas condensing boiler
BOyy Electric immersion heater (Booster Heater)
BUxx Electric immersion heater (Backup Heater)
BV Bypass valve
C Roolant compressor
CW Cold water
DHW Domestic hot water
E Expansion valve
FLS
Flow sensor, FlowSensor FLS 20 or alternative
type in accordance with tab. 6-1 (flow and feed
temperature measurement)
FLG FlowGuard regulating valve with flow indicator
GCU com-
pact
GasCombiUnit range (solar storage tank with
integrated gas condensing unit)
H
1,
H
2
... H
m
Heating circuits
HP-TR Main regulator heat pump
HPSU com-
pact
HPSU compact range (solar storage tank with
integrated heat pump unit)
MAG diaphragm expansion vessel
MIX 3-way-mixer with drive motor
MK1 Mixer group with high-efficiency pump
MK2
Mixer group with high-efficiency pump (PWM
controlled)
P High-efficiency pump
P
K
Boiler circuit pump
P
Mi
Mixing circuit pump
P
S
Solar operating pump +
P
Z
Circulation pump
PWT Panel heat exchanger (condenser)
RLB Return temperature limiter
RoCon HP HPSU compact regulation
RoCon BF Regulation A1 condensing boiler
RoCon M1 Mixer circuit control
RPS4 Solaris control and pump unit
RKHB Internal unit HPSU Bi-Bloc heat pump
RRHQ External unit HPSU Bi-Bloc heat pump
RRLQ HPSU compact outdoor unit
RT Room thermostat
S#A HYC 343/19/0-DB
S#H SCS 538/16/0-DB
SAS1 Sludge and magnetic separator
SK Solar panel field
SV Safety over-pressure valve
t
AU
Outdoor temperature sensor Rocon OT1
(included in the scope of supply of GCU com-
pact)
t
DHW
Storage tank temperature sensor (included in the
scope of supply)
t
Mi
Mixer circuit flow temperature sensor
T
K
Solar collector temperature sensor
T
R
Solar return flow temperature sensor
T
S
Solar storage cylinder temp. sensor
T
V
Solar flow temperature sensor
V Fan (vaporiser)
VS Protection against scalding VTA32
Tab. 8-1 Short names in hydraulic drawings
