User advice on disposal of your product at the end of its
life. Please see table below. In all cases check local authority
regulation before disposal.
Oil:
Unless specially ordered for extreme climatic conditions,
actuators are dispatched with gearcases filled with SAE 80EP oil
suitable for ambient temperatures ranging from -22 to 160 °F
(-30 to 70 °C).
Base assembly:
O-rings grease: Multis EP2 / Lithoshield EP2 or equivalent for
all temperature ranges.
The actuator can be removed by reversing the operations
detailed in the mounting and cabling sections. All warnings as
detailed in the mounting and cable connection sections must
be followed. Disposal of the actuator or any of its components
should be done in accordance with the table below.
WARNING: It is essential that the actuator is not
subject to any valve / system loads at the time of removal
as this could cause operator injury due to the actuator
moving unexpectedly.
Subject Definition Remarks / examples Hazardous Recyclable
EU Waste
Code
Disposal
Electrical &
Electronic
Printed circuit boards All products Yes Yes 20 01 35
Use specialist recyclers
Wire All products Yes Yes 17 04 10
Metals
Aluminium Gearcases and covers No Yes 17 04 02
Use licensed recyclers
Copper/Brass Wire, gears, motor windings No Yes 17 04 01
Zinc
CK clutch ring and associated
components
No Yes 17 04 04
Iron/Steel Gears and bases No Yes 17 04 05
Mixed Metals CK motor rotors No Yes 17 04 07
Plastics
Glass filled nylon Electronics chassis No No 17 02 04
Disposal as general
commercial waste
Unfilled Gears, window, blanking plug No Yes 17 02 03 Use specialist recyclers
Oil /Grease
Mineral Gearbox lubrication Yes Yes 13 02 04
Will require special treatment
before disposal, use specialist
recyclers or waste disposal
companies
Food Grade Gearbox lubrication Yes Yes 13 02 08
Grease Handwheel Yes No 13 02 08
Rubber Seals & O-rings Cover and shaft sealing Yes No 16 01 99
May require special treatment
before disposal, use specialist
waste disposal companies
Standard CK actuators are suitable for applications where
vibration and shock severity does not exceed the following:
Plant Induced Vibration: 1g rms total for all vibration
within the frequency range of
10 to 1000 Hz
Shock: 5g peak acceleration
Watertight: IP68 EN 60529
(8 metres for 96 hours)
Temperature: -30 to +70 °C (-22 to +158 °F)
12 Environmental11 Disposal / Recycling
