Centronik Module Nameplate
The Centronik name plate will enable you to identify your unit.
Example below:
Mark Description
1 Model
2 Serial Number
3 Main Power Supply
4 Remote Control Supply
5 Internal Customer Supply
6 Backup Supply
7 Maximum Power Rating
8 Customer Wiring Diagram
9 Internal Unit Diagram
10 Temperature Range
11 Enclosure Rating
12 Manufacturing Date
13 Unit Barcode (Factory Use)
14 QR Code
15 Capacitor Value (1ph only)
16 Spare Line (Tag Information)
Centronik Name Plate
Conduit Entries
Switch Mechanism Cover
Protective Earth Connection
(M6x1p x 10 Deep)
Plug and socket housing
Centronik Interface
Hand Wheel
Motor
Hand / Auto lever
4.3 CKc Centronik
15
1
2
3
4
5
6
7
8
9
10
11
16
12
13
14
4 Actuator Identification
